Product data sheet
Characteristics
ZCP39
limit switch body ZCP - compact - 2NC+1NO -
snap action
Main
Range of product
Series name
Device short name
Body type
Number of poles
OsiSense XC
Standard format
ZCP
Fixed
3
Complementary
Design
Associated connec component
Compact
ZCPEF12
ZCPEG11
ZCPEG13
ZCPEN12
ZCPEP16
ZCPEP20
Plastic
Zb
Silver plated contacts
0.01 m/min
C300, AC-15 (Ue = 240 V, Ie = 0.75 A) conforming to EN/IEC 60947-5-1 ap-
pendix A
R300, DC-13 (Ue = 250 V, Ie = 0.1 A) conforming to EN/IEC 60947-5-1 appendix
A
300 V conforming to CSA C22-2 No 14
300 V conforming to UL 508
400 V degree of pollution 3 conforming to IEC 60947-1
< 25 mOhm conforming to IEC 60255-7 category 3
4 kV conforming to IEC 60664
4 kV conforming to IEC 60947-1
6 A by gG cartridge fuse
5000000 cycles, DC-13 (Uc = 120 V) , 1 W, load factor: 0.5, operating rate: < 60
cyc/mn conforming to IEC 60947-5-1 appendix C
5000000 cycles, DC-13 (Uc = 24 V) , 3 W, load factor: 0.5, operating rate: < 60
cyc/mn conforming to IEC 60947-5-1 appendix C
5000000 cycles, DC-13 (Uc = 48 V) , 2 W, load factor: 0.5, operating rate: < 60
cyc/mn conforming to IEC 60947-5-1 appendix C
31 mm
65 mm
30 mm
0.07 kg
(13-14)NO
(21-22)NC
(31-32)NC
Body material
Contacts insulation form
Contacts material
Minimum actuation speed
Contact code designation
Ui rated insulation voltage
Resistance across terminals
Uimp rated imp wstdvoltage
Short circuit protection
Electrical durability
Width
Height
Depth
Product weight
Terminals description ISO n┬░1
Dec 15, 2017
1
