revision for dwg #
1PB-AFx
rev
-
ch.no.
-
2
description
original design
1
date
11/19/2007
revised by
Philipp E.
o
40 mm
[1.6 in]
7
6
5
3
4
10 mm
[.4 in]
* =
Operator includes 3x ARW1.2 and 1x ARW3.2
** =
Switch Contacts include Contact element washer and two SC24 installation screws, if more than
two contact blocks are used, additional screws must be purchased seperatly (SC45, SC65 or SC90)
ITEM DESCRIPTION
max. 6 mm
[.25 in]
16 mm
[.6 in]
55 mm
[2.2 in]
98 mm
[3.9 in]
unless otherwise specified:
all dimensions are in millimeters
third angle projection
tolerance
XX
XX.X
XX.XX
ALL
This Drawing is the property of
R
1*
=
=
=
=
±
0.5 mm
±
0.2 mm
−
mm
±
1 mm
M
E
T
R
I
C
35 Royal Road
Flemington, NJ 08822-6000
(908) 806-9400
Fax (908) 806-9490
and is a confidential
disclosurelent without
consideration other than the
borrower’s agreement that it
shall not be reproduced,
copied, lent or disposed of
directly or indirectly nor
used for any purpose other
than that for which it is
specifically furnished.
2*
3
4**
5**
6**
7**
titel
CAT. NO.
AF1
AF2
30 mm Flush Non-Illuminated
AF3
Momentary Metal Operator
AF4
AF6
AF8
Rubber washer
ARW1.2/ARW3.2
Panel
-
Contact Element washer
-
Switch Contacts
S11
Switch Contacts
S12
Contact Block Installation Screws SC25/SC45/SC65/SC90
n
35 mm
[1.4 in]
n
29 mm
[1.1 in]
COLOR
White
Black
Green
Red
Blue
Yellow
Black
-
Black
Red
Yellow
-
MIN. QTY. MAX. QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
4
-
-
1
2
1
2
1
2
2
2
30 mm Non-Illuminated Flush Momentary Metal Operator AFx
(x=color)
11/19/2007
11/19/2007
11/19/2007
drawn by:
Philipp Ernstberger
checked by:
Laszlo Gyorgypal
released by:
Laszlo Gyorgypal
drawing no.:
rev.:
-
-
1PB-AFx
scale:
sheet:
1
of:
1
