39753-0012 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 39753-0012

39753-0012: DescriptionPluggable Terminal Blocks TERMINAL PLUG HORIZ 5.00MM 12C GRN; CategoryThe connector; File Size145KB，1 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home

Download Datasheet Parametric Compare View All

39753-0012 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	39753-0012	-	-	View	Buy Now

39753-0012 Overview

Pluggable Terminal Blocks TERMINAL PLUG HORIZ 5.00MM 12C GRN

39753-0012 Parametric

Parameter Name	Attribute value
Product Category	Pluggable Terminal Blocks
Manufacturer	Molex
RoHS	Not Applicable
Product	Plugs
Number of Positions	12 Position
Pitch	5 mm
Factory Pack Quantity	360

Preview

Download Datasheet

View All

PART NUMBER DATA

CIRCUITS

.197

PART

NUMBER

397530002

397530003

397530004

397530005

397530006

397530007

397530008

397530009

397530010

397530011

397530012

.47

M450B

WIRE ENTRY

ENGINEERING

NUMBER

M450B-00-1-02-3

M450B-00-1-03-3

M450B-00-1-04-3

M450B-00-1-05-3

M450B-00-1-06-3

M450B-00-1-07-3

M450B-00-1-08-3

M450B-00-1-09-3

M450B-00-1-10-3

M450B-00-1-11-3

M450B-00-1-12-3

M450B-00-1-13-3

M450B-00-1-14-3

M450B-00-1-15-3

M450B-00-1-16-3

M450B-00-1-17-3

M450B-00-1-18-3

M450B-00-1-19-3

M450B-00-1-20-3

M450B-00-1-21-3

M450B-00-1-22-3

M450B-00-1-23-3

M450B-00-1-24-3

COLOR

GREEN

A IN mm

.39

.59

.79

.98

1.18

1.38

1.57

1.77

1.97

2.17

2.36

2.56

2.76

2.95

3.15

3.35

3.54

3.74

3.94

4.13

4.33

4.53

4.72

10.0

15.0

20.0

25.0

30.0

35.0

40.0

45.0

50.0

55.0

60.0

65.0

70.0

75.0

80.0

85.0

90.0

95.0

100.0

105.0

110.0

115.0

120.0

B IN mm

.197

.394

.591

.787

.984

1.181

1.378

1.575

1.772

1.969

2.165

2.362

2.559

2.756

2.953

3.150

3.346

3.543

3.740

3.937

4.134

4.331

4.528

5.00

10.00

15.00

20.00

25.00

30.00

35.00

40.00

45.00

50.00

55.00

60.00

65.00

70.00

75.00

80.00

85.00

90.00

95.00

100.00

105.00

110.00

115.00

REF. THE LAST 2 DIGITS OF THE PART NUMBER EQUAL CIRCUIT COUNT

.53

SPECIFICATIONS

1. MATERIAL:

A. SCREW: M2.5 STEEL, ZINC PLATED

B. BODY: PA66, UL94V-0

C. CONTACT: PHOS-BRONZE

D. CAGE: BRASS, NI PLATED

2. WIRE SIZE: 24 TO 14AWG

3.RATING: 300V, 10A

4.MAX TORQUE: 3 IN. LBS.

5.WIRE STRIP LENGTH: .20 IN. (5.0mm)

7.DIMS SHOWN ARE FOR REFERENCE ONLY

REV

CONTACT FACTORY FOR OPTIONAL COLORS

GENERAL TOLERANCES

(UNLESS SPECIFIED)

DESCRIPTION

DIMENSION STYLE

SCALE

DESIGN UNITS

IN/MM

DRAWN BY

DATE

TITLE

CHECKED BY

DATE

---

METRIC

THIRD ANGLE

PROJECTION

4 PLACES

3 PLACES

2 PLACES

1 PLACE

---

INCH

---

APPROVED BY

DATE

molex

TERMINAL PLUG-5.0MM

HORIZONTAL

----

MOLEX INCORPORATED

SHEET NO.

DRAFT WHERE

APPLICABLE

MUST REMAIN

WITHIN DIMENSIONS

MATERIAL NO.

DOCUMENT NO.

SEE CHART

SIZE

SD-39753-001

THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX

INCORPORATED AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION

39753-0012 Related Products

	39753-0012	39753-0002	39753-0006
Description	Pluggable Terminal Blocks TERMINAL PLUG HORIZ 5.00MM 12C GRN	Pluggable Terminal Blocks TERMINAL PLUG HORIZ 5.00MM 2C GRN	Pluggable Terminal Blocks TERMINAL PLUG HORIZ 5.00MM 6C GRN
Product Category	Pluggable Terminal Blocks	Pluggable Terminal Blocks	Pluggable Terminal Blocks
Manufacturer	Molex	Molex	Molex
RoHS	Not Applicable	Not Applicable	Not Applicable
Product	Plugs	Plugs	Plugs
Number of Positions	12 Position	2 Position	6 Position
Pitch	5 mm	5 mm	5 mm
Factory Pack Quantity	360	360	960
