MIL-DTL-38999
Hermetic Connectors
D38999/45
Solder Mount Hermetic Receptacle
MIL-DTL-38999 Series IV
How To Order:
MS
B
Basic Specification
H
D38999
G
A
Connector
B
Material / Finish
N
- CRES, Nickel
C
K
Y
-
J
CRES, Passivated
D
E
Insert Arrangement
Per MIL-STD-1560;
See Pages B2 - B4
Alternate Key Position
A, B, C, D, K, L, M, R, U
(N = Normal)
D38999
Shell Style
F
/45
B
C
D
E
Y
B
35
P
N
/45
-
Solder Mount
Shell Size
- 11
F
- 19
- 13
G
- 21
- 15
H
- 23
- 17
J
- 25
Contact Termination
P
- Pin, Solder Cup
S
- Socket, Solder Cup
X
- Pin, Eyelet
Z
- Socket, Eyelet
C
- Pin, PCB
D
- Socket, PCB
Flex Feedthrough
Flex Feedthrough
Non-Environmental
Rear Accessory Thread Adapter
Available for this Receptacle
See P/N 980-002 on Page B-90
.118 (3.0) Max
.175/.125
Feedthrough
Contact (C)
P (See Table II)
Master Key (Blue)
Insert
Arrangements
per MIL-DTL-38999
Series IV
.819 (20.8)
.756 (19.2)
.047 (1.19)
.024 (0.6)
A
B
J
C
D
D
Solder Cup
Contact (P)
Eyelet
Contact (X)
ø A Max
H
G
F
K
E
B
.035
.007
.438
Max
Dimensions in Inches (millimeters) are subject to change without notice.
© 2013 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
B-86
