SHEET 1 OF 1
5.08
[.200 in]
9.27
[.365 in]
12.70
[.500 in]
1.85
[.073 in]
1.22
[.048 in]
5.08
[.200 in]
POS. 2
1
3.81
[.150 in]
4
2
5
3
6
4.70
[.185 in]
3.18
[.125 in]
RECOMMENDED P.C. MOUNTING
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
2
ON
2-3, 5-6
NONE
N/A
ON
2-1, 4-5
1
3
4
6
5
7.87
[.310 in]
POS. 1
25
POS. 3
ACTUATOR COLOR:
BLACK
.40
[.016 in]
CIRCUIT: DPDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X= 0.4
X.XX= 0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: GOLD
5. RATING: 0.4 VOLT-AMPS MAX. @20V MAX. AC OR DC
6. ELECTRIC LIFE: 30,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
9. OPERATING TEMP.: -30 C to 85 C
10.
DENOTES CRITICAL PARAMETER.
11. 2011/65/EU (ROHS) COMPLIANT
B
A
REV
22706
13948
PCR NO
UPDATED LAYOUT AND TERMINALS
RELEASED FOR PRODUCTION
DESCRIPTION
E-SWITCH MARKING
OPPOSITE SIDE
3
6
.76
[.030 in]
4.70
[.185 in]
12.70
[.500 in]
2
5
1
4
4.52
[.178 in]
12.7
[.50 in]
11.43
[.450 in]
1
4
3.81
[.150 in]
1.27
[.050 in]
EPOXY
SEAL
2/15/17
4/22/04
DATE
MJR
AR
BY
SCALE
DATE
DR
DWG
REV
TITLE
300AWDP1J1BLKM6RE
2:1
4/22/2004
AR
T301006
B
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
