HEF4051B-Q100
8-channel analog multiplexer/demultiplexer
Rev. 1 — 12 July 2012
Product data sheet
1. General description
The
HEF4051B-Q100
is an 8-channel analog multiplexer/demultiplexer with three address
inputs (S1 to S3), an active LOW enable input (E), eight independent inputs/outputs
(Y0 to Y7) and a common input/output (Z). The device contains eight bidirectional analog
switches, each with one side connected to an independent input/output (Y0 to Y7) and the
other side connected to a common input/output (Z). With E LOW, one of the eight
switches is selected (low-impedance ON-state) by S1 to S3. With E HIGH, all switches
are in the high-impedance OFF-state, independent of S1 to S3. If break before make is
needed, then it is necessary to use the enable input.
V
DD
and V
SS
are the supply voltage connections for the digital control inputs (S1 to S3,
and E). The V
DD
to V
SS
range is 3 V to 15 V. The analog inputs/outputs (Y0 to Y7, and Z)
can swing between V
DD
as a positive limit and V
EE
as a negative limit. V
DD
V
EE
may not
exceed 15 V. Unused inputs must be connected to V
DD
, V
SS
, or another input. For
operation as a digital multiplexer/demultiplexer, V
EE
is connected to V
SS
(typically
ground). V
EE
and V
SS
are the supply voltage connections for the switches.
This product has been qualified to the Automotive Electronics Council (AEC) standard
Q100 (Grade 1) and is suitable for use in automotive applications.
2. Features and benefits
Automotive product qualification in accordance with AEC-Q100 (Grade 1)
Specified from
40 C
to +85
C
and from
40 C
to +125
C
Fully static operation
5 V, 10 V, and 15 V parametric ratings
Standardized symmetrical output characteristics
ESD protection:
MIL-STD-833, method 3015 exceeds 2000V
HBM JESD22-A114F exceeds 2000 V
MM JESD22-A115-A exceeds 200 V (C = 200 pf, R = 0
)
Complies with JEDEC standard JESD 13-B
3. Applications
Analog multiplexing and demultiplexing
Digital multiplexing and demultiplexing
Signal gating
NXP Semiconductors
HEF4051B-Q100
8-channel analog multiplexer/demultiplexer
4. Ordering information
Table 1.
Ordering information
All types operate from
40
C to +125
C.
Type number
HEF4051BT-Q100
HEF4051BTT-Q100
Package
Name
SO16
TSSOP16
Description
plastic small outline package; 16 leads; body width 3.9 mm
plastic thin shrink small outline package; 16 leads; body width 4.4 mm
Version
SOT109-1
SOT403-1
5. Functional diagram
V
DD
16
13 Y0
S1 11
14 Y1
15 Y2
S2 10
12 Y3
LOGIC
LEVEL
CONVERSION
S3 9
1
−
OF
−
8
DECODER
1 Y4
5 Y5
2 Y6
E 6
4 Y7
3 Z
8
V
SS
7
V
EE
001aac277
Fig 1.
Functional diagram
HEF4051B_Q100
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2012. All rights reserved.
Product data sheet
Rev. 1 — 12 July 2012
2 of 21
NXP Semiconductors
HEF4051B-Q100
8-channel analog multiplexer/demultiplexer
6. Pinning information
6.1 Pinning
HEF4051B-Q100
Y4
Y6
Z
Y7
Y5
E
V
EE
V
SS
1
2
3
4
5
6
7
8
aaa-003493
16 V
DD
15 Y2
14 Y1
13 Y0
12 Y3
11 S1
10 S2
9
S3
1
2
3
4
5
6
7
8
aaa-003494
HEF4051B-Q100
Y4
Y6
Z
Y7
Y5
E
V
EE
V
SS
16 V
DD
15 Y2
14 Y1
13 Y0
12 Y3
11 S1
10 S2
9
S3
Fig 6.
Pin configuration SOT109-1
Fig 7.
Pin configuration SOT403-1
6.2 Pin description
Table 2.
Symbol
E
V
EE
V
SS
S1, S2, S3
Z
V
DD
Pin description
Pin
6
7
8
11, 10, 9
3
16
Description
enable input (active LOW)
supply voltage
ground supply voltage
select input
independent input or output
common output or input
supply voltage
Y0, Y1, Y2, Y3, Y4, Y5, Y6, Y7 13, 14, 15, 12, 1, 5, 2, 4
HEF4051B_Q100
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2012. All rights reserved.
Product data sheet
Rev. 1 — 12 July 2012
5 of 21
