Feed-through header - MSTBV 2,5/ 8-GF - 1776948
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
PCB headers, nominal current: 12 A, rated voltage (III/2): 320 V, number of positions: 8, pitch: 5 mm, color:
green, contact surface: Tin, mounting: Wave soldering
The figure shows a 10-position
version of the product
Your advantages
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Well-known mounting principle allows worldwide use
Vertical connection enables multi-row arrangement on the PCB
Key Commercial Data
Packing unit
GTIN
GTIN
4017918039110
100 pc
Technical data
Dimensions
Length [ l ]
Width
Pitch
Dimension a
Width [ w ]
Height [ h ]
Height
Length of the solder pin
Pin dimensions
Length
8.6 mm
50 mm
5 mm
35 mm
50 mm
15.9 mm
12 mm
3.9 mm
1 x 1 mm
8.6 mm
General
10/28/2018 Page 1 / 4
https://www.phoenixcontact.com/pi/products/1776948
Feed-through header - MSTBV 2,5/ 8-GF - 1776948
Technical data
General
Range of articles
Insulating material group
Rated surge voltage (III/3)
Rated surge voltage (III/2)
Rated surge voltage (II/2)
Rated voltage (III/3)
Rated voltage (III/2)
Rated voltage (II/2)
Connection in acc. with standard
Nominal current I
N
Maximum load current
Insulating material
Flammability rating according to UL 94
Color
Number of positions
MSTBV 2,5/..-GF
IIIa
4 kV
4 kV
4 kV
250 V
320 V
400 V
EN-VDE
12 A
12 A
PBT
V0
green
8
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
EN-VDE
CSA
V0
Environmental Product Compliance
REACh SVHC
China RoHS
Lead 7439-92-1
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
Drawings
Drilling diagram
a
5
5
7,5
Dimensional drawing
15
a+15
2,4
3,8
22
12
3,9
1,4
3,8
8,6
5
5
a
7,5
Approvals
Approvals
10/28/2018 Page 2 / 4
https://www.phoenixcontact.com/pi/products/1776948
Feed-through header - MSTBV 2,5/ 8-GF - 1776948
Approvals
Approvals
DNV GL / CSA / RS / IECEE CB Scheme / VDE Gutachten mit Fertigungsüberwachung / EAC / cULus Recognized
Ex Approvals
Approval details
DNV GL
http://exchange.dnv.com/tari/
TAE00001EY
CSA
Nominal voltage UN
Nominal current IN
D
300 V
10 A
http://www.csagroup.org/services-industries/product-listing/
B
300 V
12 A
13631
RS
http://www.rs-head.spb.ru/en/index.php
17.00014.272
IECEE CB Scheme
Nominal voltage UN
Nominal current IN
http://www.iecee.org/
250 V
12 A
DE1-58978-B1B2
VDE Gutachten mit
Fertigungsüberwachung
Nominal voltage UN
Nominal current IN
http://www2.vde.com/de/Institut/Online-Service/
VDE-gepruefteProdukte/Seiten/Online-Suche.aspx
250 V
12 A
40004701
EAC
B.01742
10/28/2018 Page 3 / 4
https://www.phoenixcontact.com/pi/products/1776948
Feed-through header - MSTBV 2,5/ 8-GF - 1776948
Approvals
cULus Recognized
Nominal voltage UN
Nominal current IN
D
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm E60425-19931011
B
300 V
12 A
300 V
10 A
