HOME PHONE NETWORKING
BANDPASS FILTER
For use with Broadcom’s
®
iLine 10
™
Chipset
(BCM4100 and BCM4210)
Includes isolation and EMI filtering
Designed to withstand 235°C peak infrared
reflow temperature
B6019 is designed with a 2 kV, 1000 pf capacitor
Electrical Specifications @ 25°C — Operating Temperature -40°C to +85°C
Part
Number
Insertion Loss
@ 4.75 to 9.25 MHz
(MIN)
(MAX)
Attenuation
(MIN)
1.1 MHz 22 MHz
54 MHz
Return Loss
@ 4.75 to 9.25 MHz
(MIN)
12 dB
Common to Differential
Mode Rejection
@ 200 kHz to 22 MHz
40 dB
Isolation
Voltage
1
(Vrms)
1500
B6019
B6020
1.0 dB
2.0 dB
60 dB
35 dB
50 dB
BX6031
NOTE:
Input Impedance data is provided on the back of this page.
Test Conditions
Part
Number
B6019
B6020
Insertion Loss
Input
(1-3)
Output
(20-18)
Attenuation
Input
(1-3)
Output
(20-18)
Return Loss
Input
(20-18)
Output
(1-3)
Common to Differential
Mode Rejection
Input
Output
(1-3)
(20-18)
Isolation
Voltage
1
(1-3-5-7) shorted
to (18-20) shorted
(1-2-15-16) shorted
BX6031
(1-2)
(8-9)
(1-2)
(8-9)
(8-9)
(1-2)
(1-2)
(8-9)
to (8-9-10) shorted
NOTES:
Filters are shipped in trays, unless Tape & Reel packaging is specified. Please add the suffix "T" (ex: B6019T) for Tape & Reel orders.
1
Compliance with FCC Part 68 metallic and longitudinal voltage surge is provided by an external Teccor P3100SB sidactor across tip and ring.
Mechanicals
B6019/B6020
20X
.018 ± .002
0,46 ± 0,05
BX6031
.918
23,32
16 15
10 9
1.145
29.08
B6019/B6020
COUNTRY OF ORIGIN
DATE CODE (REV)
1.170
29.72
1.015
25.78
20X
.028
0,71
.450
11,43
.390 .530
9,91 13,46
.625
15,88
.450
11,43
.050
1,27
.500
12,70
1
DATE CODE
COUNTRY OF ORIGIN
BX6031
2
7
8
.100
2,54
.700
17,78
.040
8X 1,02
1.005
25.53
SUGGESTED PAD LAYOUT
.245
6,22
.050
1,27
8X .018
0,46
4X
.100
2,54
SUGGESTED PAD LAYOUT
.380
9,65
0° 8°
.225
5,72
8X .035
0,89
.700
17,78
0° 8°
20X
.045
1,14
.010
0,25
.004/0,10
20 SURFACES
.004/0,10
8 SURFACES
.010
0,25
B6019/B6020
BX6031
Weight
......................4.5 grams .............2.5 grams
Tape & Reel.................250/reel
................250/reel
Tube
..............................30/tray ..................20/tray
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are ± .010
0,25
US 858 674 8100
•
UK 44 1483 401 700
•
France 33 3 84 35 04 04
•
Singapore 65 287 8998
•
Taiwan 886 2 2698 0228
•
Hong Kong 852 2788 6588
•
http://www.pulseeng.com
B964.B (6/02)
HOME PHONE NETWORKING
BANDPASS FILTER
Schematics
B6019
TURNS RATIO: (20-18):(1-3)=1:0.667
(20-18):(5-7)=1:2
Input Impedance
Frequency Range
(kHz)
0 < f < = 0.285
0.285 < f < = 2.85
2.85 < f < = 28.5
28.5 < f < = 95
95 < f < = 190
Minimum Impedance
(Ω)
1M
100 K
10 K
4.0 K
2.0 K
1.4 K
1.0 K
850
700
600
525
450
400
350
175
100
50
25
10
10
25
50
100
50
CHIP
TRANSMIT
WINDING 3
RECEIVE 5
WINDING
7
1
1000
pF
MEDIA
20 TIP
Band
Pass
Filter
18 RING
16
190 < f < = 285
285 < f < = 380
380 < f < = 475
475 < f < = 570
570 < f < = 665
665 < f < = 760
760 < f < = 855
855 < f < = 950
950 < f < = 1000
1000 < f < = 1400
1400 < f < = 2300
2300 < f < = 2850
2850 < f < = 3085
NOTE:
Input impedance is measured across pins 18 to 20 with a 44.2
Ω
load across pins 1 and 3.
B6020
TURNS RATIO: (20-18):(1-3)=1:0.667
(20-18):(5-7)=1:2
CHIP
1
TRANSMIT
WINDING 3
RECEIVE
WINDING 7
5
MEDIA
20 TIP
Band
Pass
Filter
18 RING
16 TRANSFORMER
CENTER TAP
3085 < f < = 4750
9250 < f < = 13125
13125 < f < = 14175
14175 < f < = 16800
16800 < f < = 21000
21000 < f < = 30000
NOTE:
Input impedance is measured across pins 18 to 20 with a 44.2
Ω
load across pins 1 and 3.
BX6031
TURNS RATIO: (8-9):(1-2)=1:0.667
(8-9):(16-15)=1:2
CHIP
1
TRANSMIT
WINDING 2
RECEIVE 16
WINDING
15
MEDIA
8 TIP
Band
Pass
Filter
9 RING
10 TRANSFORMER
CENTER TAP
NOTE:
Input impedance is measured across pins 9 to 8 with a 44.2
Ω
load across pins 1 and 2.
