PRAHT 100, PRAHT 135, PRAHT 182 (CNWHT)
www.vishay.com
Vishay Sfernice
High Temperature (230 °C) High Precision
Thin Film Wraparound Chip Resistor Arrays, Sulfur Resistant
FEATURES
• Tight TCR (10 ppm/°C) and TCR tracking
(to 2 ppm/°C)
• 2 to 4 resistors (same or different values)
• Ratio tolerance to 0.05 %
• Gold terminations for temperature up to 230 °C
Available
• High temperature (230 °C)
• SnAg terminations for temperature up to 200 °C
Available
• SMD wraparound chip resistor array
• Thin film technology
• Very low noise < -35 dB and voltage coefficient
< 0.01 ppm/V
• Sulfur resistant (per ASTM B809-95 humid vapor test)
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
PRAHT arrays can be used in most applications requiring a
matched pair (or set) of resistor elements at very high
temperature up to 230 °C. The networks provide 2 ppm/°C
TCR tracking, a ratio tolerance as tight as 0.05 % and
outstanding stability.
They are available in pitch:
• 1.00 mm for PRAHT 100 (based on case 0603)
• 1.35 mm for PRAHT 135 (based on case 0805)
• 1.82 mm for PRAHT 182 (based on case 1206)
TYPICAL PERFORMANCE
ABSOLUTE
TCR
TOL.
10 ppm/°C
ABSOLUTE
0.5 %
TRACKING
2 ppm/°C
RATIO
0.05 %
DIMENSIONS
Independent resistors
B
DIM.
PRAHT 100
(0603 base)
mm
mil
60
±6
PRAHT 135
(0805 base)
mm
1.91
± 0.152
mil
75
±6
PRAHT 182
(1206 base)
mm
3.06
± 0.152
mil
120
±6
A
D
E
One common point
F
A
C
1.52
± 0.152
B
0.5
± 0.127
0.38
± 0.13
1
0.7
± 0.1
0.49
0.66
2.57
20
±5
15
±5
40
27.6
±4
19.3
26
101.2
B = N x E (± 0.2 mm)
B = N x E (± 8 mil)
0.5
± 0.127
0.38
± 0.13
1.35
1.05
± 0.1
0.88
1.01
2.96
20
±5
15
±5
53
41.4
±4
34.5
39.8
116.5
0.5
± 0.127
0.40
± 0.13
1.825
1.525
± 0.1
1.99
1.49
4.11
20
±5
16
±5
72
60
±4
78.3
58.7
161.8
B
C
A
D
E
F
D
E
C
F
Suggested land pattern
(according to IPC-7351A)
G
min.
X
max.
Z
max.
G
min.
X
max.
Z
max.
E
Revision: 29-Mar-17
Document Number: 53057
1
For technical questions, contact:
sferthinfilm@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
PRAHT 100, PRAHT 135, PRAHT 182 (CNWHT)
www.vishay.com
Vishay Sfernice
(1)
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: PRAHT100I4-1K00BWGT
P
R
A
H
T
1
0
0
I
4
-
1
K
0
0
B
W
G
T
GLOBAL MODEL
PRAHT 100
PRAHT 135
PRAHT 182
CONFIG.
I:
independent
C:
common
NUMBERS OF
RESISTORS
2 to 4
VALUE
(2)
Decimal
R or K
ABS. TOL.
D
= 0.5 %
F
=1%
B
= 0.1 %
RATIO TOL.
B
= 0.1 %
W
= 0.05 %
TERMINATION
(3)
N:
SnAg over
nickel barrier
G:
gold over
nickel barrier
PACKAGING
For more
information see
“Codification of
Packaging” table
N
and
G:
lead (Pb)-free/RoHS version
For different ohmic values on a given network a specific part number is used
CNWHT
GLOBAL
MODEL
2027
T
For more information see
“Codification of
Packaging” table
REFERENCE
Notes
(1)
Part number can only have 18 digits. Depending on infomation needed a compromise has to be found. A codification can be used to identify
case size + configuration and number of resistors. See table below.
E.g. PRAHT100I4-4K75BWGTA (Part number has more than 18 digts): PRAHT100I4 must be replaced by PRAHT17 =
PRAHT17-4K75BWGTA
(2)
When the last digit(s) of the ohmic value is (are) 0, it (they) can be omitted.
E.g.: PRAHT100I4-2K20BWGT
can be ordered under PRAHT100I4-2K2BWGT
PRAHT100I4-1K00BWGT
can be ordered under PRAHT100I4-1KBWGT
(3)
N termination for temperature up to 200 °C.
G termination for temperature up to 230 °C
CODIFICATION OF SIZE + CONFIGUATION + NUMBER OF RESISTORS
CODE 18
1
2
3
4
5
6
7
8
9
10
11
12
13
14
CODE 40
PRAHT073I2
PRAHT073I3
PRAHT073I4
PRAHT073I5
PRAHT073I6
PRAHT073I7
PRAHT073I8
PRAHT074I2
PRAHT074I3
PRAHT074I4
PRAHT074I5
PRAHT074I6
PRAHT074I7
PRAHT074I8
CODE 18
15
16
17
18
19
20
21
22
23
24
25
26
27
28
CODE 40
PRAHT100I2
PRAHT100I3
PRAHT100I4
PRAHT100I5
PRAHT100I6
PRAHT100I7
PRAHT100I8
PRAHT135I2
PRAHT135I3
PRAHT135I4
PRAHT135I5
PRAHT135I6
PRAHT135I7
PRAHT135I8
CODE 18
29
30
31
32
33
34
35
36
37
38
39
40
41
42
CODE 40
PRAHT182I2
PRAHT182I3
PRAHT182I4
PRAHT182I5
PRAHT182I6
PRAHT182I7
PRAHT182I8
PRAHT073C2
PRAHT073C3
PRAHT073C4
PRAHT073C5
PRAHT073C6
PRAHT073C7
PRAHT073C8
CODE 18
43
44
45
46
47
48
49
50
51
52
53
54
55
56
CODE 40
PRAHT074C2
PRAHT074C3
PRAHT074C4
PRAHT074C5
PRAHT074C6
PRAHT074C7
PRAHT074C8
PRAHT100C2
PRAHT100C3
PRAHT100C4
PRAHT100C5
PRAHT100C6
PRAHT100C7
PRAHT100C8
CODE 18
57
58
59
60
61
62
63
64
65
66
67
68
69
70
CODE 40
PRAHT135C2
PRAHT135C3
PRAHT135C4
PRAHT135C5
PRAHT135C6
PRAHT135C7
PRAHT135C8
PRAHT182C2
PRAHT182C3
PRAHT182C4
PRAHT182C5
PRAHT182C6
PRAHT182C7
PRAHT182C8
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
PRAHT 100
PRAHT 135
PRAHT 182
SIZE
100
135
182
RESISTANCE
RANGE
10 to 250K
10 to 500K
10 to 2M
POWER
RATING PER
RESISTOR
(1)
W
0.010
0.0125
0.020
ABSOLUTE
TOLERANCE
±%
0.1, 0.5, 1
0.1, 0.5, 1
0.1, 0.5, 1
RATIO
TOLERANCE
%
0.05, 0.1
0.05, 0.1
0.05, 0.1
ABSOLUTE
TCR
(2)
± ppm/°C
15
15
15
RATIO
TCR
(2)
± ppm/°C
2
2
2
Notes
(1)
At +215 °C
(2)
At -40 °C to +215 °C
Revision: 29-Mar-17
Document Number: 53057
2
For technical questions, contact:
sferthinfilm@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
PRAHT 100, PRAHT 135, PRAHT 182 (CNWHT)
www.vishay.com
Vishay Sfernice
MECHANICAL SPECIFICATIONS
Substrate
Technology
Film
Alumina
Thin Film
Nickel chromium with mineral passivation
N type: SnAg over nickel barrier
G type: Gold over nickel barrier
-55 °C to +215 °C
-55 °C to +230 °C
CLIMATIC SPECIFICATIONS
Operating temperature range
Storage temperature range
PERFORMANCE VS. HUMID SULFUR VAPOR
Test conditions
Test results
50 °C ± 2 °C, 85 % ± 4 % RH,
exposure time 500 h
Resistance drift < (0.05 %
R
+ 0.05
),
no corrosion products observed
Terminations
(1)
Note
(1)
N terminations for temperatures up to 200°C.
G terminations for temperatures up to 230°C
PERFORMANCES
TEST
Noise
Voltage coefficient
PRAHT 100
Limiting voltage
PRAHT 135
PRAHT 182
SPECIFICATIONS
-35 dB
0.01 ppm/V
50 V
100 V
150 V
PACKAGING
Several types of packaging are available: Waffle-pack and
tape and reel.
NUMBER OF PIECES PER PACKAGE
WAFFLE PACK
TAPE AND REEL
MOQ MAX. QUANTITY
MIN.
MAX.
PER BOX
100
140
60
140
100
60
60
60
60
50
100
2000
4000
2000
100
4000
100
4000
PACKAGING RULES
Waffle Pack
Can be filled up to maximum quantity indicated in the table
here above, taking into account the minimum order quantity.
When quantity ordered exceeds maximum quantity of a
single waffle pack, the waffle packs are stacked up on the
top of each other and closed by one single cover.
To get “not stacked up” waffle pack in case of ordered
quantity > maximum number of pieces per package:
Please consult Vishay Sfernice for specific ordering
code.
Tape and Reel
Can be filled up to maximum quantity indicated in the table
here above, taking into account the minimum order quantity.
When quantity ordered is between the MOQ and the
maximum reel capacity, only one reel is provided.
When several reels are needed for ordered quantity
within MOQ and maximum reel capacity: Please consult
Vishay Sfernice for specific ordering code.
SIZE
PRA100 x 2
PRA100 x 3
PRA100 x 4
PRA135 x 2
PRA135 x 3
PRA135 x 4
PRA182 x 2
PRA182 x 3
PRA182 x 4
DERATING
350
300
RATED POWER IN %
MARKING
On the primary package, printed information includes
Vishay S.A. trademark series and model, schematic number
of resistors, ohmic value, absolute tolerance, ratio tolerance,
type of termination: B tinned over nickel barrier.
Marking on parts:
8
7
6
5
250
200
150
100
50
0
0
50
100
150
200
250
M
1
R1
C
2
R2
D
3
R3
U
4
R4
AMBIENT TEMPERATURE IN °C
E.g.: Ohmic value 13K:
coded 1302: M = 1, C = 3, D = 0, U = 2
Revision: 29-Mar-17
Document Number: 53057
3
For technical questions, contact:
sferthinfilm@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
PRAHT 100, PRAHT 135, PRAHT 182 (CNWHT)
www.vishay.com
Vishay Sfernice
PERFORMANCE
DRIFTS
TESTS
CONDITIONS
CECC REQUIREMENTS
2.5 Un/2 s
-55 °C to +155 °C/5 moisture cycles
-55 °C to +155 °C/5 cycles 30'
1000 h/Pn at 215 °C
Load life
8000 h/Pn at 215 °C
Resistance to solder heat
Moisture resistance
High temperature storage
Note
• Rn: nominal resistance
260 °C/10 s
0.01 Pn at +40 °C 93 % RH
1000 h/no load at +155 °C
0.7 % Rn
0.05 % Rn + 0.05
0.1 % Rn + 0.05
0.1 % Rn + 0.05
0.4 % Rn
0.01 % Rn
0.01 % Rn
0.02 % Rn
ABSOLUTE PER
(Typical Values)
0.05 % Rn + 0.05
0.1 % Rn + 0.05
0.05 % Rn + 0.05
0.5 % Rn
RATIO
0.01 % Rn
0.01 % Rn
0.01 % Rn
0.25 % Rn
Overload
Climatic sequences
Thermal shock
CODIFICATION OF PACKAGING
CODE 18
WAFFLE PACK
W
PLASTIC TAPE
T
TA
TB
TC
TD
TE
TF
100 min., 1 mult
100 min., 100 mult
250 min., 250 mult
500 min., 500 mult
1000 min., 1000 mult
2500min., 2500 mult
Full tape (quantity depending on size of chips)
100 min., 1 mult
PACKAGING
Revision: 29-Mar-17
Document Number: 53057
4
For technical questions, contact:
sferthinfilm@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Legal Disclaimer Notice
www.vishay.com
Vishay
Disclaimer
ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively,
“Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained in any datasheet or in any other
disclosure relating to any product.
Vishay makes no warranty, representation or guarantee regarding the suitability of the products for any particular purpose or
the continuing production of any product. To the maximum extent permitted by applicable law, Vishay disclaims (i) any and all
liability arising out of the application or use of any product, (ii) any and all liability, including without limitation special,
consequential or incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular
purpose, non-infringement and merchantability.
Statements regarding the suitability of products for certain types of applications are based on Vishay’s knowledge of
typical requirements that are often placed on Vishay products in generic applications. Such statements are not binding
statements about the suitability of products for a particular application. It is the customer’s responsibility to validate that a
particular product with the properties described in the product specification is suitable for use in a particular application.
Parameters provided in datasheets and / or specifications may vary in different applications and performance may vary over
time. All operating parameters, including typical parameters, must be validated for each customer application by the customer’s
technical experts. Product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase,
including but not limited to the warranty expressed therein.
Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining
applications or for any other application in which the failure of the Vishay product could result in personal injury or death.
Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk.
Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for
such applications.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document
or by any conduct of Vishay. Product names and markings noted herein may be trademarks of their respective owners.
© 2017 VISHAY INTERTECHNOLOGY, INC. ALL RIGHTS RESERVED
Revision: 08-Feb-17
1
Document Number: 91000
京公网安备 11010802033920号
EEWORLD
