1701446 Overview

Pluggable Terminal Blocks MCD 1,5/ 4-G- 3,81 GY7035

1701446 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	PHOENIX CONTACT
Reach Compliance Code	compliant
Terminal and terminal strip types	BARRIER STRIP TERMINAL BLOCK

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/hq/products/1701446

Header - MCD 1,5/ 4-G-3,81 GY7035 - 1701446

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

Header, Nominal current: 8 A, Number of positions: 4, Pitch: 3.81 mm, Color: light gray, Contact surface: Tin,

Mounting: Wave soldering

Key Commercial Data

Packing unit

GTIN

Custom tariff number

Note

4046356535595

85366990

Made to Order (non-returnable)

50 STK

Technical data

Dimensions

Pitch

Dimension a

Constructional height

Length of the solder pin

3.81 mm

11.43 mm

23 mm

3.5 mm

General

Range of articles

Rated voltage (III/3)

Connection in acc. with standard

Nominal current I

N

Color

Number of positions

MCD 1,5/..-G

160 V

EN-VDE

8A

light gray

4

Standards and Regulations

Connection in acc. with standard

EN-VDE

CSA

Environmental Product Compliance

China RoHS

Environmentally friendly use period: unlimited = EFUP-e

No hazardous substances above threshold values

11/14/2016 Page 1 / 2
