SAB-C505A-4EM datasheet, PDF - EEWORLD Datasheet

SAB-C505A-4EM: DescriptionMicrocontroller, 8-Bit, OTPROM, 8051 CPU, 20MHz, CMOS, PQFP44, METRIC, PLASTIC, QFP-44; CategoryThe embedded processor and controller Microcontrollers and processors; File Size817KB，88 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric View All

SAB-C505A-4EM Overview

Microcontroller, 8-Bit, OTPROM, 8051 CPU, 20MHz, CMOS, PQFP44, METRIC, PLASTIC, QFP-44

Parameter Name	Attribute value
Maker	Infineon
Parts packaging code	QFP
package instruction	QFP, QFP44,.5SQ,32
Contacts	44
Reach Compliance Code	compliant
Has ADC	YES
Address bus width	16
bit size	8
CPU series	8051
maximum clock frequency	20 MHz
DAC channel	NO
DMA channel	NO
External data bus width	8
JESD-30 code	S-PQFP-G44
length	10 mm
Number of I/O lines	34
Number of terminals	44
Maximum operating temperature	70 °C
Minimum operating temperature
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Encapsulate equivalent code	QFP44,.5SQ,32
Package shape	SQUARE
Package form	FLATPACK
power supply	5 V
Certification status	Not Qualified
RAM (bytes)	1280
rom(word)	32768
ROM programmability	OTPROM
Maximum seat height	2.45 mm
speed	20 MHz
Maximum supply voltage	5.5 V
Minimum supply voltage	4.25 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	QUAD
width	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER
Base Number Matches	1

D at a S hee t, De c. 2 00 0

C505

C505C

C505A

C505CA

8-Bit Single-Chip Microcontroller

Microcontrollers

N e v e r

s t o p

t h i n k i n g .
