3287-6100-TD

Description
RF Connectors / Coaxial Connectors SMPM Male Surface Mount (Tin Dipped) Connector, FD
CategoryThe connector
File Size79KB,1 Pages
ManufacturerAmphenol
Websitehttp://www.amphenol.com/
Download Datasheet Parametric View All

3287-6100-TD Online Shopping

Suppliers Part Number Price MOQ In stock
3287-6100-TD - - View Buy Now

3287-6100-TD Overview

RF Connectors / Coaxial Connectors SMPM Male Surface Mount (Tin Dipped) Connector, FD

3287-6100-TD Parametric

Parameter NameAttribute value
Product CategoryRF Connectors / Coaxial Connectors
ManufacturerAmphenol
RF SeriesSMPM
PackagingBag
Factory Pack Quantity50
ROHS COMPLIANT
PRODUCT DATA DRAWING
REV
REVISION HISTORY
DESCRIPTION
DATE
APPROVED
-
DCN 42490
07/16
DAL
RP
.150 3.81
.067±.001 1.70±0.03
.009 0.23
.125 3.18
NOTE 2
3
A
.085 2.16
CONTACT & INSULATOR
FLUSH TO .005
BELOW -B-
B
NOTE 2
.030 0.76
SOLDER
.012±.001 0.30±0.03
A
.028±.001 0.71±0.03
NOTE 2
NOTES:
1.
STAINLESS STEEL
BERYLLIUM COPPER
TORLON
2.
3.
MATERIAL
:
BODY:
CONTACT:
INSULATOR:
FOR RECOMMENDED FOOTPRINT TO YOUR SPECIFIC
PCB, CONTACT SV MICROWAVE SALES DEPARTMENT
(sales@svmicro.com, 561-840-1800)
TO BE TIN DIPPED USING Sn96 SOLDER
ALL DIMENSIONS APPLY PRIOR TO SOLDER DIPPING
FINISH
:
BODY & CONTACT:
GOLD OVER NICKEL
.152 3.86
PART NUMBER
3287-6100
3287-6101
DIMENSIONS ARE IN INCHES TOLERANCES:
FRACTIONAL:
DECIMAL: .X
.XX
.XXX
1/64
.030
.010
.005
ANGULAR: X
X X'
1 0'
15'
INTERFACE
FULL DETENT
SMOOTH BORE
PERFORMANCE
:
IMPEDANCE:
FREQ. RANGE:
VSWR:
50 OHMS
DC TO 20.0 GHz.
1.20:1 DC TO 20.0 GHz.
MATERIAL:
FINISH:
SEE NOTES
SEE NOTES
N/A
PROPRIETARY
UNLESS OTHERWISE SPECIFIED
1) ALL DIMENSIONS ARE IN INCHES [MILLIMETERS]
2) ALL DIMENSIONS ARE AFTER PLATING.
3) BREAK CORNERS & EDGES .005 R. MAX.
4) CHAM. 1ST & LAST THREADS.
5) SURFACE ROUGHNESS 63
e
MIL-STD-10.
6) DIA.’S ON COMMON CENTERS TO BE CONCENTRIC
WITHIN .005 T.I.R.
7) REMOVE ALL BURRS
SV Microwave, Inc.
2400 Centrepark West Drive, Suite 100
West Palm Beach, FL 33409
TITLE:
SURFACE AREA:
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.5M - 1994
SMPM MALE PC MOUNT
WITH R/A CONTACT
95077
THE INFORMATION CONTAINED IN THIS DRAWING
IS THE SOLE PROPERTY OF SV MICROWAVE, INC.
ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
SV MICROWAVE, INC IS PROHIBITED.
THIRD ANGLE PROJECTION
DRAWN:
CHECKED:
APPROVED:
JMC 02/16/06
STW 02/16/06
STW 02/16/06
SIZE CAGE CODE DWG. NO.
B
3287-610X-TD
SHEET 1 OF 1
SCALE: 4:1
