SHT1X PROTO
The SHT1X PROTO additional board is used measure temperature and relative humidity.
Key features:
- Serial communication;
- Measuring humidity (0 - 100%);
- Measuring temperature (-40 to +125C
o
);
- Low power consumption; and
- 2.4 to 5.5V power supply voltage.
Figure 1:
SHT1X PROTO additional board
How to connect the board?
The SHT1X PROTO additional board is connected to a microcontroller or some other device via pads CN1. Communication
is performed via serial communication. Only two communication lines are used for this purpose: SDA - serial data transfer
and SCL - serial clock.
Figure 2:
SHT1X PROTO board connection schematic
Figure 3:
Dimensions of the board
