Cable kit , Riser Cards &
I/O modules
PCM-10586-9562E
Part No.
1700160160
1700002142
1700260250
1700019109
1703100260
1703060191
1700008941
1700001296
1700100250
1703150102
170304015K
Cable Description
Audio cable
Ethernet cable
LPT port cable
COM 4/5 cable
USB Port cable
PS2 KB/MS Cable
SATA Cable
VGA cable
COM1/2/3
SATA Power Cable
AT power cable
1
2
1
1
4
1
3
1
3
3
1
Installation Wiring Kit for PCM-9562
Quantity
PCM-9562 Connector
CN4
CN10, CN12
CN15
CN42
CN20, CN21, CN28, CN29
CN25
CN32, CN33, CN34
CN8
CN39, CN40, CN41
None
CN5
Terminating Connector
Cable 16-Pin (2.0 mm) Audio 16 cm
Ethernet Cable IDC10P 2.0 mm/RJ45 15cm
Cable 25 cm 25P to 26P ASS'Y LPT Port 2.0 mm
A Cable 2 x 5P-2.0/D-SUB(M) 9P+D-SUB(M) 9P 25 cm
Wire 10P 26 cm 2.0 mm For USB 2 PORT
Cable 6P-2.0 mm Housing/6P (PS/2)/6P (K/B) 19 cm
Cable 7P/7P SATA L=30cm Lock
VGA Cable D-SUB 3 x 5P(F)/2x 8P-2.0 15 cm
F Cable IDE#2 10P-2.0/D-SUB 9P(M) 25 cm
SATA Power cable L= 10 cm
A Cable 2 x 2P-4.2/B4P-5.08 x 2 15 cm
Ordering Information
PCM-10586-9562E
PCM-9562 cable kit
PCI Riser Card
PCM-110
1-Slot PCI Riser Card for 5.25"
Biscuit SBCs
PCM-261
LVDS/TTL to DVI Module
Fits in PCM-95XX series
Provides bracket to secure Biscuit SBCs
Size: 103.7 x 56 mm (4.08" x 2.2")
Supports 18 and 24-bit LVDS to DVI
Supports 18 or 24-bit TTL LCD to DVI (optional)
Ordering Information
P/N
PCM-110-00A3E
Description
1-slot PCI riser Card for Biscuit SBCs
Specifications
General
Chipset
Silicon Image SiI 164; NS DS90CF364
LCD Connector
Hirose Output Connector; DVI
Mechanical and Environmental
Dimensions (L x W)
72 x 62 mm
Weight
0.029 kg (0.064 lb)
Operating Temperature
0 ~ 60° C (32 ~ 140° F)
Operating Humidity
0% ~ 90% relative humidity, non-condensing
Power
Power Supply Voltage
+5 V, ±5%
Ordering Information
Standard
PCM-261L-A0A1E
PCM-261L-B0A1E
PCM-261T-A0A1E
24-bit LVDS to DVI Module
18-bit LVDS to DVI Module
24-bit TTL to DVI Module
Packing List
1 x User manual
1 x PCM-261 board
Embedded Single Board Computers
All product specifications are subject to change without notice
Last updated : 15-Jan-2014
