MAX4983EEVKIT- Overview

Switch IC Development Tools MAX4983E/84E Eval Kit

MAX4983EEVKIT- Parametric

Parameter NameAttribute value
Product CategorySwitch IC Development Tools
ManufacturerMaxim
RoHSDetails
ProductEvaluation Kits
TypeUSB Switches
Tool Is For Evaluation OfMAX4983E
Interface TypeUSB
PackagingBulk
Description/FunctionHigh ESD-protected DPDT switch
Operating Supply Voltage5 V
Factory Pack Quantity1
19-4155; Rev 0; 5/08
MAX4983E Evaluation Kit
General Description
The MAX4983E evaluation kit (EV kit) provides a proven
design to evaluate the MAX4983E high ESD-protected
double-pole/double-throw (DPDT) switch. The EV kit is
designed to demonstrate the MAX4983E ICs used in
USB 2.0 high-speed (480Mbps) switching applications.
The EV kit routes a single USB signal between one of
two type-A USB ports.
The MAX4983E EV kit PCB comes with a MAX4983EEVB+
installed.
o
USB Powered (Cable Included)
o
Complete USB 2.0 (480Mbps) Switching Circuit
o
On-Board VBUS Power-Switching Circuit
o
Lead-Free and RoHS Compliant
o
Proven PCB Layout
o
Fully Assembled and Tested
Features
Evaluates: MAX4983E/MAX4984E
Ordering Information
PART
MAX4983EEVKIT+
TYPE
EV Kit
+Denotes
lead-free and RoHS compliant.
Component List
DESIGNATION
QTY
DESCRIPTION
0.1µF ±10%, 16V X7R ceramic
capacitors (0603)
Murata GRM188R71C104K
TDK C1608X7R1C104K
10µF ±10%, 16V X5R ceramic
capacitors (0805)
Murata GRM21BR61C106K
1µF ±10%, 16V X5R ceramic
capacitor (0603)
Murata GRM188R61C105K
TDK C1608X5R1C105K
Green LED (0603)
Ferrite bead (0603)
TDK MMZ1608R301A
3 pin headers, 0.1in centers
Not installed, chip inductors—short
(PCB trace) (0603)
USB series-B right-angle PC-mount
receptacle
U2
1
3
1
DESIGNATION
P2, P3
Q1
Q2
R1
R2, R3
QTY
2
1
1
1
2
DESCRIPTION
USB series-A right-angle PC-mount
receptacles
Dual n-channel MOSFET (6 SSOT)
Fairchild Semi FDC6305N
Dual p-channel MOSFET (6 SSOT)
Fairchild Semi FDC6312P
270Ω ±5% resistor (0603)
10kΩ ±5% resistors (0603)
High-speed USB 2.0 switches
(10 UTQFN)
Maxim MAX4983EEVB+
(Top Mark: AAA)
3.3V linear regulator (5 SC70)
Maxim MAX8511EXK33+T
(Top Mark: AEI)
Shunts
PCB: MAX4983E Evaluation Kit+
C1, C3, C5, C6
4
C2, C4
2
C7
1
D1
FB1
JU1, JU2, JU3
L1, L2
P1
1
1
3
0
1
U1
1
Component Suppliers
SUPPLIER
Fairchild Semiconductor
Murata Electronics North America, Inc.
TDK Corp.
PHONE
888-522-5372
770-436-1300
847-803-6100
WEBSITE
www.fairchildsemi.com
www.murata-northamerica.com
www.component.tdk.com
Note:
Indicate that you are using the MAX4983E or MAX4984E when contacting these component suppliers.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
