CMLM0574-TR

Description
MOSFET N-Ch 450mA MOSFET u0026 40V 500mA Schottky
Categorysemiconductor    Discrete semiconductor
File Size513KB,3 Pages
ManufacturerCentral Semiconductor
Download Datasheet Parametric View All

CMLM0574-TR Online Shopping

Suppliers Part Number Price MOQ In stock
CMLM0574-TR - - View Buy Now

CMLM0574-TR Overview

MOSFET N-Ch 450mA MOSFET u0026 40V 500mA Schottky

CMLM0574-TR Parametric

Parameter NameAttribute value
Product CategoryMOSFET
ManufacturerCentral Semiconductor
RoHSDetails
TechnologySi
Package / CaseSOT-563-6
PackagingReel
Factory Pack Quantity3000
Unit Weight0.000106 oz
CMLM0574
Multi Discrete Module
SURFACE MOUNT SILICON
N-CHANNEL MOSFET AND
LOW VF SCHOTTKY DIODE
w w w. c e n t r a l s e m i . c o m
DESCRIPTION:
The CENTRAL SEMICONDUCTOR CMLM0574 is a
Multi Discrete Module™ consisting of a single N-Channel
enhancement-mode MOSFET and a low VF Schottky
diode packaged in a space saving SOT-563 surface
mount case. This device is designed for small signal
general purpose applications where size and operational
efficiency are prime requirements.
MARKING CODE: 57C
SOT-563 CASE
• Device is
Halogen Free
by design
FEATURES:
• ESD protection up to 2kV
• Low rDS(on) Transistor (560mΩ MAX @ VGS=2.5V)
• Low VF Schottky Diode (0.47V MAX @ 0.5A)
SYMBOL
PD
PD
PD
TJ, Tstg
Θ
JA
SYMBOL
VDS
VGS
ID
SYMBOL
VRRM
IF
IFRM
IFSM
350
300
150
-65 to +150
357
UNITS
mW
mW
mW
°C
°C/W
UNITS
V
V
mA
UNITS
V
mA
A
A
APPLICATIONS:
• DC-DC Converters
• Battery Powered Portable Equipment
MAXIMUM RATINGS - CASE:
(TA=25°C)
Power Dissipation (Note 1)
Power Dissipation (Note 2)
Power Dissipation (Note 3)
Operating and Storage Junction Temperature
Thermal Resistance
MAXIMUM RATINGS - Q1:
(TA=25°C)
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current
MAXIMUM RATINGS - D1:
(TA=25°C)
Peak Repetitive Reverse Voltage
Continuous Forward Current
Peak Repetitive Forward Current, tp≤1.0ms
Peak Forward Surge Current, tp= 8.0ms
30
8.0
450
40
500
3.5
10
ELECTRICAL CHARACTERISTICS - Q1:
(TA=25°C unless otherwise noted)
SYMBOL
TEST CONDITIONS
MIN
TYP
IGSSF, IGSSR VGS=8.0V, VDS=0
IDSS
VDS=30V, VGS=0
BVDSS
VGS=0, ID=10μA
30
VGS(th)
VDS=VGS, ID=250μA
0.5
VSD
VGS=0, IS=400mA
0.5
VGS=4.5V, ID=200mA
280
rDS(ON)
rDS(ON)
VGS=2.5V, ID=100mA
390
rDS(ON)
VGS=1.8V, ID=75mA
550
gFS
VDS =10V, ID=100mA
200
Notes:
(1) Ceramic or aluminum core PC Board with copper mounting pad area of 4.0mm
2
(2) FR-4 Epoxy PC Board with copper mounting pad area of 4.0mm
2
(3) FR-4 Epoxy PC Board with copper mounting pad area of 1.4mm
2
MAX
3.0
1.0
1.0
1.1
460
560
730
UNITS
μA
μA
V
V
V
mS
R4 (1-July 2015)
