MIC6211
Micrel
MIC6211
IttyBitty™ Operational Amplifier
Preliminary Information
General Description
The MIC6211 IttyBitty™ op amp is a general-purpose, high-
performance, single- or split-supply, operational amplifier in
a space-saving, surface-mount package.
The MIC6211 operates from 4V to 32V, single or differential
(split) supply. The input common-mode range includes ground.
The device features a 2.5MHz unity gain bandwidth, 6V/µs
slew rate, and is internally unity-gain compensated.
Inputs are protected against reverse polarity (input voltage
less than V–) and ESD (electrostatic discharge). Output is
current limited for both sourcing and sinking. Output short
circuits of unlimited duration are allowed, provided the power
dissipation specification is not exceeded.
The MIC6211 is available in the tiny, 5-lead SOT-23-5 sur-
face-mount package.
Features
•
•
•
•
•
•
4V to 32V operation
Small footprint package
Unity gain stable
2.5 MHz unity gain bandwidth
6V/µs typical slew rate
Short circuit protected
Applications
• Analog blocks
• Active filtering
Ordering Information
Part Number
MIC6211BM5
Temperature Range
–40°C to +85°C
Package
SOT-23-5
Pin Configuration
IN+
3
Functional Configuration
V– OUT
2
1
IN+
3
V– OUT
2
1
A11
4
5
Part
Identification
4
5
IN–
V+
IN–
V+
SOT-23-5 (M5)
Pin Description
Pin Number
1
2
3
4
5
Pin Name
OUT
V–
IN+
IN–
V+
Pin Function
Amplifier Output
Negative Supply: Negative supply for split supply application or ground for
single supply application.
Noninverting Input
Inverting Input
Positive Supply
Micrel, Inc. • 1849 Fortune Drive • San Jose, CA 95131 • USA • tel + 1 (408) 944-0800 • fax + 1 (408) 944-0970 • http://www.micrel.com
June 1999
1
MIC6211
MIC6211
Micrel
Absolute Maximum Ratings
Supply Voltage (V
V+
– V
V–
) ............................. 36V or
±18V
Differential Input Voltage (V
IN+
– V
IN–
) .......................
±36V
Input Voltage (V
IN+
, V
IN–
) ..................... (V
V–
– 0.3V) to V
V+
Output Short Circuit Current Duration ...............................∞
Operating Ratings
Supply Voltage .................................................... 4V to 32V
Ambient Temperature Range ..................... –40°C to +85°C
SOT-23-5 Thermal Resistance (θ
JA
) ..................... 220°C/W
(mounted to printed circuit board)
Electrical Characteristics (Differential Supply)
V+ = +15V, V– = –15V, V
CM
= 0V; R
L
= 2kΩ; T
A
= 25°C,
bold
values indicate –40°C
≤
T
A
≤
+85°C, T
A
= T
J
; unless noted
Symbol
V
OS
TCV
OS
I
B
I
OS
V
CM
CMRR
PSRR
A
VOL
V
OUT
B
W
S
R
I
SC
I
S
Parameter
Input Offset Voltage
Average Input Offset Drift
Input Bias Current
Input Offset Current
Input Voltage Range
Common Mode Rejection Ratio
Power Supply Rejection Ratio
Large Signal Voltage Gain
Maximum Output Voltage Swing
Bandwidth
Slew Rate
Output Short Circuit Current
Supply Current
Sourcing or sinking
30
V
CM
= +13.5V, –15.0V
V
S
=
±2.5V
to
±15V
V
O
=
±10V
+13.5
–15.0
65
65
25
±12.5
Note 1
Condition
Min
Typ
2
7
50
8
+13.8
–15.3
100
110
180
±14
2.5
6
50
1.3
2.0
250
30
Max
7
Units
mV
µV/°C
nA
nA
V
V
dB
dB
V/mV
V
MHz
V/µs
mA
mA
Electrical Characteristics (Single Supply)
V+ = +5V, V– = 0V, V
CM
= 0.1V; T
A
= 25°C,
bold
values indicate –40°C
≤
T
A
≤
+85°C, T
A
= T
J
; unless noted
Symbol
V
OS
TCV
OS
I
B
I
OS
V
CM
CMRR
PSRR
A
VOL
V
OUT
I
SC
I
S
Note 1:
Parameter
Input Offset Voltage
Average Input Offset Drift
Input Bias Current
Input Offset Current
Input Voltage Range
Common Mode Rejection Ratio
Power Supply Rejection Ratio
Large Signal Voltage Gain
Maximum Output Voltage Swing
Output Short Circuit Current
Supply Current
Condition
Min
Typ
2
Max
7
Units
mV
µV/°C
Note 1
7
65
8
+3.5
0
+3.7
–0.3
70
105
170
+4.0
+1.0
40
1.2
1.8
+1.2
250
30
nA
nA
V
V
dB
dB
V/mV
V
V
mA
mA
V
CM
= 0V to 3.5V
V
S
=
±2.5V
to
±15V
V
O
= 1.5V to 3.5V, R
L
= 2k
R
L
= 10k to GND
R
L
= 10k to +5V
Sourcing or sinking
45
65
15
+3.8
20
General Note:
Devices are ESD protected; however, handling precautions are recommended.
Not production tested.
MIC6211
2
June 1999
MIC6211
Micrel
Typical Characteristics
Supply Current
vs. Temperature
1.4
INPUT BIAS CURRENT (nA)
SUPPLY CURRENT (mA)
V
S
=
±15V
1.3
80
70
60
50
40
30
-40 -20 0 20 40 60 80 100
TEMPERATURE (°C)
V =
±15V
S
INPUT OFFSET CURRENT (nA)
90
Input Bias Current
vs. Temperature
20
Input Offset Current
vs. Temperature
15
V
S
=
±15V
10
V
S
= 5V
1.2
V = 5V
S
1.1
5
V
S
= 5V
1.0
-40 -20 0 20 40 60 80 100
TEMPERATURE (°C)
0
-40 -20 0 20 40 60 80 100
TEMPERATURE (°C)
1.5
SUPPLY CURRENT (mA)
Supply Current
vs. Supply Voltage
120
100
VOLTAGE GAIN (dB)
Voltage Gain
vs. Frequency
30
Gain and Phase
vs. Frequency
45
90
135
PHASE (°)
V
S
=
±15V
VOLTAGE GAIN (dB)
20
10
PHASE
1.0
80
60
40
20
0
10,000
10
100
1,000
0.1
72°
0
-10
V
S
=
±15V
-20
0.1
1.0
FREQUENCY (MHz)
270
10
GAIN
180
225
0.5
0
5
10 15 20 25
SUPPLY VOLTAGE (V)
30
0.01
FREQUENCY (kHz)
Large-Signal Transient Response
1
0
-20
Small-Signal Transient Response
OUTPUT VOLTAGE
OUTPUT VOLTAGE
+10V
GND
–10V
AV = +1
RL = 2k
CL = 10pF
VS =
±15V
+50mV
GND
–50mV
AV = +1
RL = 2k
CL = 100pF
VS =
±15V
INPUT VOLTAGE
+10V
GND
–10V
2µs/DIV
INPUT VOLTAGE
+50mV
GND
–50mV
500ns/DIV
June 1999
3
MIC6211
MIC6211
Micrel
PEAK-TO-PEAK OUTPUT VOLTAGE (V)
30
25
20
15
10
5
0
10
Large-Signal
Frequency Response
V
S
=
±15V
R
L
= 2k
T
A
= 25°C
110
100
CMRR (dB)
Common Mode Rejection Ratio
vs. Frequency
V
S
=
±15V
130
120
110
Power Supply Rejection
Ratio vs. Frequency
V =
±15V
S
PSRR (dB)
90
80
70
60
100
90
80
70
60
-PSRR
+PSRR
100
1000 3000
FREQUENCY (kHz)
50
0.01
0.1
1
10
100
FREQUENCY (kHz)
1000
50
0.001 0.01 0.1
1
10
FREQUENCY (kHz)
100
SHORT CIRCUIT CURRENT (mA)
65
60
55
50
45
Short Circuit Current
vs. Temperature
V
S
=
±15V
40
-40 -20 0 20 40 60 80 100
TEMPERATURE (°C)
0.1Hz to 10Hz Noise
VS =
±15V
Wideband Noise
V
S
=
±15V
NOISE VOLTAGE (4µV/DIV)
1s/DIV
NOISE VOLTAGE (5µV/DIV)
5ms/DIV
MIC6211
4
June 1999
MIC6211
Micrel
Functional Diagram
V+
5
20Ω
–IN
4
1
V
OUT
20Ω
C
C
3
+IN
2
MIC6211
V–
(GND)
June 1999
5
MIC6211
