CRS01W
SCHOTTKY BARRIER RECTIFIER DIODE
Absolute Maximum Ratings (T
a
= 25
o
C)
Symbol
Peak Repetitive Reverse Voltage
Average Forward Current
Non-Repetitive Peak One Cycle Surge Forward Current
At 50Hz
At 60Hz
Junction Temperature Range
Storage Temperature Range
V
RRM
I
F(AV)
Value
30
1.0
Unit
V
A
I
FSM
I
FSM
T
j
T
S
20
22
-40 to +125
-40 to +125
A
℃
℃
Characteristics at T
amb
= 25℃
Symbol
Peak Forward Voltage
at I
FM
= 0.1A
at I
FM
= 0.7A
at I
FM
= 1.0A
Repetitive Peak Reverse Current
at V
RRM
= 30V
Junction Capacitance
at V
R
= 10V, f=1MHz
Thermal Resistance
On ceramic substrate
On glass-epoxy substrate
V
FM
V
FM
V
FM
I
RRM
C
J
Min.
-
-
-
-
-
Typ.
0.25
0.33
0.36
-
40
Max.
-
0.37
-
1.5
-
Unit
V
mA
pF
R
th(j-a)
-
-
-
-
70
140
℃/W
SEMTECH ELECTRONICS LTD.
(Subsidiary
of Sino-Tech International Holdings Limited, a company
listed on the Hong Kong Stock Exchange, Stock Code: 724)
®
Dated : 21/05/2005
CRS01W
PACKAGE OUTLINE
Plastic surface mounted package; 2 leads
SOD-123
∠
ALL ROUND
H
E
A
b
p
E
UNIT
mm
A
1.15
1.05
b
0.6
0.5
c
0.135
0.127
D
2.7
2.6
E
1.65
1.55
H
3.9
3.7
v
0.2
∠
5°
SEMTECH ELECTRONICS LTD.
(Subsidiary
of Sino-Tech International Holdings Limited, a company
listed on the Hong Kong Stock Exchange, Stock Code: 724)
®
Dated : 21/05/2005
