This document was generated on 09/15/2011
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0022426050
Active
kk
2.54mm (.100") KK® IDT Double Cantilever Contact, 5 Circuits, Tin (Sn), Feed-
Through, 22 AWG Wire
Documents:
3D Model
Drawing (PDF)
Product Specification PS-7720-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series
image - Reference only
L19980
E29179
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Low-Halogen Status
Low-Halogen
China RoHS
Agency Certification
CSA
UL
General
Product Family
Series
Comments
Crimp Quality Equipment
Overview
Product Name
IDT and Solder Connectors
7720
Double Cantilever contact
Yes
kk
KK®
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
Circuits (Loaded)
Color - Resin
Durability (mating cycles max)
Flammability
Gender
Glow-Wire Compliant
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Packaging Type
Panel Mount
Pitch - Mating Interface
Polarized to Mating Part
Temperature Range - Operating
Termination Interface: Style
Wire Size AWG
5
Natural
5
94V-2
Female
No
None
Phosphor Bronze
Tin
Tin
Nylon
1
Bag
No
2.54mm (.100")
Yes
0°C to +75°C
IDT or Pierce
22 Stranded
Search Parts in this Series
7720Series
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Insertion Tool for
0638133504
2.54mm (.100") Pitch
KK® IDT Crimp
Terminals
Changehead for
0690080225
7720 and 7720s
Connector Range,
Color Bar In, Feed-
To Only
Arbor Press Fixture 0690200320
for 7720 and
7720s Insulation
Displacement
Housings, 2-28
Electrical
Current - Maximum per Contact
Voltage - Maximum
4A
250V
Material Info
Old Part Number
A-7720-WA05F154B
Reference - Drawing Numbers
Product Specification
Sales Drawing
PS-7720-001
SD-7720-001
Circuit, 24-28 AWG
Wire/ Ribbon Cable
IDT - Manual Press 0011200179
IDT - Semi-automatic 0011200771
- Bench-Top
Terminator
IDT - Semi-automatic 0623000100
- Bench-Top
Terminator
This document was generated on 09/15/2011
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
