external influences such as PCB construction, circuit
layout etc. As such, external components in addition
to those listed herein may be required in specific
instances to gain full compliance to the standards
specified.
[2]
[3]
Compatible with SurfMate and InMate socketing system
Not intended for socket or Surfmate mounting
M-FIAM9
Page 1 of 7
Rev 3.4
06/2017
vicorpower.com
800 927.9474
M-FIAM9M21
Specifications
(Typical at T
BP
= 25°C, nominal line and 75% load, unless otherwise specified)
INPUT SPECIFICATIONS
Parameter
Input voltage
Inrush limiting
Min
10
Typ
28
Max
36
0.007
Unit
V
DC
A/µF
Notes
Continuous
Intended for use in Military Ground Vehicles where the power
available is per MIL-STD-1275D. Internal capacitance is
~50µF, which precedes the inrush limit circuit. External
precautions should be taken if the source cannot tolerate the
capacitive charge current associated with this
internal capacitance.
Transient immunity
100
250
70
50
V
DC
V
DC
V
DC
V
DC
50ms per MIL-STD-1275A/B/D, continuous operation
70µs per MIL-STD-1275A/B/D, continuous operation
20ms per MIL-STD-704A, continuous operation
12.5ms per MIL-STD-704E/F, continuous operation
OUTPUT SPECIFICATIONS
Parameter
Output power
Output current
Efficiency
Internal voltage drop
External capacitance
330
1000
µF
96
97
0.85
Min
Typ
Max
500
18
1.5
Unit
W
A
%
V
500W, 25°C baseplate
See Figure 7 on page 5
50V
Notes
See Figures 5 & 6
CONTROL PIN SPECIFICATIONS
Parameter
ON/OFF control
Enable (ON)
Disable (OFF)
Min
0.0
3.5
Typ
Max
1.0
5.0
Unit
V
DC
V
DC
Notes
Referenced to – V
OUT
100kΩ internal pull up resistor
SAFETY SPECIFICATIONS
Parameter
Dielectric withstand
Min
1,500
2,121
Typ
Max
Unit
V
RMS
V
DC
Notes
Input/Output to Base
Input/Output to Base
EMI
Standard
MIL-STD-461E
Conducted emissions:
Conducted susceptibility:
Test Procedure
CE101, CE102
CS101, CS114, CS115, CS116
Notes
When using with V28 series converters a 27µH inductor is
needed between the filter and converter for compliance
below 30% of rated power.
EMI performance is subject to a wide variety of external influences such as PCB construction, circuit layout etc. As such, external components in addition
to those listed herein may be required in specific instances to gain full compliance to the standards specified.
M-FIAM9
Page 2 of 7
Rev 3.4
06/2017
vicorpower.com
800 927.9474
M-FIAM9M21
Specifications (Cont.)
GENERAL SPECIFICATIONS
Parameter
Weight
Warranty
Min
Typ
Max
3.3 (94)
2
Unit
Ounces (grams)
Years
Notes
ENVIRONMENTAL QUALIFICATION
Altitude
MIL-STD-810F, Method 500.4, Procedure I & II, 40,000ft. and 70,000ft. Operational.
Explosive Atmosphere
MIL-STD-810F, Method 511.4, Procedure I, Operational.
Vibration
MIL-STD-810F, Method 514.5, Procedure I, Category 14, Sine and Random vibration per Table 514.5C for Helicopter AH-6J Main Rotor with overall level
of 5.6Grms for 4 hours per axis. MIL-STD-810F, Method 514.5C, General Minimum Integrity Curve per Figure 514.5C-17 with overall level of 7.7Grms
for 1 hour per axis.
Shock
MIL-STD-810F, Method 516.5, Procedure I, Functional Shock, 40g. MIL-S-901D, Lightweight Hammer Shock, 3 impacts / axis, 1,3,5 ft.
