FEATURES
* 33-100W Isolated Output
* 4:1 Wide Input Range
* Chassis Mount/Din Rail Mount
* Input Over Voltage Protection
* Regulated Outputs
* Continuous Short Circuit Protection
* CE Mark Meets 2004/108/EEC
* Safety Meets UL60950-1, EN60950-1, and IEC60950-1
CHASSIS MOUNT
DC-DC CONVERTERS
QUARTER BRICK PACKAGE
WITH HEATSINK
33 TO 100 WATT 4:1 INPUT RANGE
* UL60950-1 Approval for DC Modules
Ordering Information
CHB(E)XXX-
Model No.
XX
Nominal Input Voltage
S
XX
Output Voltage
3V3 : 3.3VDC
05 : 5VDC
12 : 12VDC
15 : 15VDC
24 : 24VDC
48 : 48VDC
05 : 5VDC
12 : 12VDC
24 : 24VDC
N
Remote On/Off
-XXX
+X-XXXX
Heat Sink Type
(Option)
CQE50W
CQB75W
CQB100W
CQE50W
CQB100
24: 24VDC
48: 48VDC
Single Output
CM: Chassis Mount
None: Positive Logic DIN: Din Rail Mount
N: Negative Logic
M-C448
M-C421
110: 110VDC
Require input an aluminum capacitor connected in the table below.
MODEL NUMBER
CQE50W-XXSXX-CM/DIN
CQB75W-XXSXX-CM/DIN
CQB100W-XXSXX-CM/DIN
CQB100-110SXX-CM/DIN
NOTE:
INPUT
220uF/100V for 24Vin Models
47uF/100V for 48Vin Models
220uF/100V for 24Vin Models
100uF/100V for 24Vin Models
47uF/100V for 48Vin Models
120uF/200V
1. Short JP1 to connect +S and +Vo, JP2 to connect –S and –Vo with local sense.
2. Remove jumper( JP1& JP2),terminal block port +S, -S & Trim can be used to Output Remote Sensing or Output
Voltage Adjustment functional(see application note).
3. Thermal resistance is referenced to the application note.
4. Include TVS for input surge voltage protection.
5. Recommend external fuse for input reverse polarity protection (Include shunt diode inside).
6. Suffix “DIN” to the Model number with din mount, the clip is suitable for TS-35 din rail.
1
V11
POWER DERATING CURVE
Typical Derating Curves At Nominal Line, Full Load, and natural convection
CQE50W-48S12-CM/DIN Typical Power De-rating Curve
120%
79 85
100%
80%
Load
Load
100%
120%
28
46
CQB75W-48S12-CM/DIN Typical Power De-rating Curve
80%
60%
M-C448
60%
M-C448
40%
20%
M-C421
40%
M-C421
20%
0%
-40 -30 -20 -10
0
10
20
30
40
50
60
70
80
90 100 110
0%
-40 -30 -20 -10
0
10
20
30
40
50
60
70
80
90 100 110
Temperature(
℃
)
Temperature(
℃
)
CQB100W-48S12-CM/DIN Typical Power De-rating Curve
120%
20
100%
80%
Load
Load
40
100%
80%
120%
CQB100-110S12-CM/DIN Typical Power De-rating Curve
55
66
60%
M-C448
60%
M-C448
40%
20%
M-C421
40%
20%
M-C421
0%
-40 -30 -20 -10
0
10
20
30
40
50
60
70
80
90 100 110
0%
-40 -30 -20 -10
0
10
20
30
40
50
60
70
80
90 100 110
Temperature(
℃
)
Temperature(
℃
)
Mechanical Specification
PIN CONNECTIONS
PIN
1,2
3
4,5
6,7
8
9
FUNCTION
+V Input
On/Off
+V Input
+V Output
+Sense
Trim
PIN
10
11,12
JP1
JP2
FUNCTION
-Sense
- V Output
Short +S& +Vo
Short –S& -Vo
Suffix -CM (Left Side) / Suffix–DIN(Right Side)
