THIS DRAWING IS A CONTROLLED DOCUMENT.
LOC
DIST
-
-
REVISIONS
P
LTR
DESCRIPTION
DATE
DWN
APVD
1
NEW DRAWING
19JUN2013
RS
EC
SAFETY ORGANIZATIONS
THIS FILTER HAS BEEN DESIGNED TO THE FOLLOWING
STANDARDS, BUT HAS NOT YET BEEN FORMALLY RECOGNIZED,
CERTIFIED OR APPROVED BY THE LISTED AGENCIES.
ALL TEST REQUIREMENTS SPECIFIED IN THE LATEST REVISION
OF THE FOLLOWING AGENCY STANDARDS WILL BE MET:
RELIABILITY SPECIFICATIONS
STORAGE TEMPERATURE:
HUMIDITY:
-40 $ C TO +85 $ C
21 DAYS
@ 40 $ C AND 95% RH
TEST SPECIFICATIONS
INDUCTANCE:
36.8 µH NOMINAL
CAPACITANCE
@ 1 kHz, 0.25 VAC MAX., 25 $ C # 1 $ C:
LINE TO GROUND:
2.62 µF
LINE TO LINE:
12.3 µF
OPERATING SPECIFICATIONS
LINE CURRENT/VOLTAGE:
LINE FREQUENCY:
NOMINAL LEAKAGE CURRENT:
MAXIMUM LEAKAGE CURRENT:
20
1000 A, 520 VAC
50-60 Hz
6 mA
222 mA
@ 277 V, 50 Hz
DISCHARGE RESISTOR
L-G AND L-L:
666k ^ / 666k ^
IR, L/L @ 20 $ C, 50% RH: 6000M ^ (MIN.)
@100VDC
RECOMMENDED RECEIVING INSPECTION HIPOT
LINE TO GROUND:
LINE TO LINE:
2200 VDC FOR 1 MINUTE
2160 VDC FOR 1 MINUTE
OPERATING AMBIENT TEMPERATURE RANGE
@ RATED CURRENT, I :
-10 $ C TO +50 $ C
AT AMBIENT TEMPERATURE, T ,
ABOVE MAX RATED I , THE
MAXIMUM OPERATING CURRENT, I ,
IS DETERMINED BY THIS EQUATION:
100 - T
O
R
FILTER APPROVAL:
Q
I = I
RELEASED FOR PUBLICATION
50
THE BEST WAY TO SELECT AND QUALIFY
A FILTER IS FOR YOUR ENGINEERING TO
TEST THE UNIT IN YOUR EQUIPMENT.
LOAD
30.00
145.00
145.00
12.00
8.00
ALL RIGHTS RESERVED.
255.0
280.0
LINE
230.0
60.0
55.0
12.0
*
53.0
SCALE
350.0
1:10
14.00
170.0
64
47.0
33.0
40.00
BY -
THIS DRAWING IS UNPUBLISHED.
* DO NOT LOOSEN INNER GROUND NUTS.
TORQUE OUTER GROUND NUTS TO:
25-30 NM [220-260 IN-LB]
COMMON MODE 50/50
TYPICAL INSERTION LOSS
20
COPYRIGHT
^ ; DIFFERENTIAL MODE 100/100
^
MHz
CM
DIMENSIONS:
DWN
CHK
APVD
PRODUCT SPEC
0.01
12
32
0.05
13
46
0.15
56
60
FINISH
0.5 1.0 3.0 5.0
71
62
67
58
49
46
45
41
10
37
35
30
18
27
mm
TOLERANCES UNLESS
OTHERWISE SPECIFIED:
RS
EC
EC
19JUN2013
19JUN2013
19JUN2013
DM
MATERIAL
C
-
-
TE Connectivity
0 PLC
1 PLC
2 PLC
3 PLC
4 PLC
ANGLES
2.0
0.1
0.01
0.005
0.0001
-
APPLICATION SPEC
NAME
-
WEIGHT
-
Customer Drawing
1469-35 (3/11)
-
A4
00779
SIZE
CAGE CODE
1000ACPV12
3-PHASE DELTA FILTER
DRAWING
NO
RESTRICTED TO
8-1609148-5-25
SCALE
1:1
SHEET
1
OF
1
REV
-
1
