1701228 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 1701228

1701228: DescriptionFixed Terminal Blocks GSMKDS 3/10; CategoryThe connector; File Size70KB，4 Pages; ManufacturerPHOENIX CONTACT; Websitehttps://www.phoenixcontact.com

Download Datasheet Parametric View All

1701228 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1701228	-	-	View	Buy Now

1701228 Overview

Fixed Terminal Blocks GSMKDS 3/10

1701228 Parametric

Parameter Name	Attribute value
Product Category	Fixed Terminal Blocks
Manufacturer	PHOENIX CONTACT
RoHS	Details
Number of Positions	10 Position
Pitch	7.5 mm
Connection Method	Screw
Current Rating	24 A
Voltage Rating	630 V
Mounting Angle	35 deg
Product	Fixed Terminal Blocks
Factory Pack Quantity	50
Termination Style	Through Hole
Unit Weight	0.455669 oz

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/us/products/1701228

PCB terminal block - GSMKDS 3/10 - 1701228

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

PCB terminal block, Nominal current: 24 A, Nom. voltage: 630 V, Pitch: 7.5 mm, Number of positions: 10,

Connection method: Screw connection with tension sleeve, Mounting: Wave soldering, Conductor/PCB

connection direction: 55 °, Color: green

Key Commercial Data

Packing unit

Minimum order quantity

Weight per Piece (excluding packing)

Custom tariff number

Country of origin

1 pc

50 pc

23.2 g

85369010

Germany

Technical data

Dimensions

Length

Pitch

Dimension a

Constructional height

Length of the solder pin

Pin dimensions

Hole diameter

16 mm

7.50 mm

67.5 mm

18 mm

4.5 mm

0,9 x 0,9 mm

1.3 mm

General

Range of articles

Rated surge voltage (III/3)

Rated surge voltage (III/2)

Rated surge voltage (II/2)

Rated voltage (III/3)

Rated voltage (III/2)

Rated voltage (II/2)

Connection in acc. with standard

Nominal current I

GSMKDS 3

6 kV

500 V

630 V

1000 V

EN-VDE

24 A

04/20/2016 Page 1 / 4
