Bushings, Grommets, HEYCaps and Plugs
Heyco Metric Snap Bushings
®
Multiple Locking Steps for Panel Thickness up to 2,5 mm (.098˝)
Mounting Hole Diameter Range: 16,0 mm (.630˝) to 34,2 mm (1.347˝)
•
Same design as Heyco Snap
Bushings but
designed for metric
sized mounting holes.
•
Convert raw-edged holes to smooth,
neat insulated holes.
•
Locking fingers snap into holes
with fingertip pressure.
•
Withstand a push back force of
35 pounds.
•
Lock firmly into panel up to
2,5 mm (.098˝) thick.
•
Multiple sizes for use in 16,0 mm
(.630˝ ) to 32,0 mm (1.260˝)
diameter holes. For other metric
sizes, consult Heyco.
•
For our complete range of Snap
Bushings, see pages 6-3 thru 6-8.
MOUNTING
HOLE
DIAMETER
mm.
NEW!
13,0
16,0
20,0
22,0
25,0
28,0
32,0
34,2
in.
.512
.630
.787
.866
.984
1.102
1.260
1.347
2150
2142
2144
2168
2146
2188
2148
2190
MSB 13-10
MSB 16-12
MSB 20-16
MSB 22-18
MSB 25-19
MSB 28-24
MSB 32-26
MSB 34-26
PART NO.
Black
DESCRIPTION
A
Inside
Diameter
mm.
in.
10,0
12,0
16,0
18,2
19,0
24,0
26,0
26,2
.39
.47
.63
.71
.75
.95
1.02
1.03
PART DIMENSIONS
B
Head
Diameter
mm.
in.
13,7
18,5
22,6
24,1
27,8
31,3
34,9
36,8
.54
.73
.89
.95
1.09
1.24
1.38
1.45
C
Overall
Height
mm.
in.
10,3
.41
NEW!
NEW!
NEW!
11,5
.45
Standard color black. Consult Heyco for white and other colors.
C
B
B
C
Metric Snap Bushing
A
A
Rubber Grommets
Heyco UL Listed Thermoplastic Rubber Grommets
®
For Panel Thickness from .03˝ (0,8 mm) to .08˝ (2,0 mm)
Mounting Hole Diameter Range: .500˝ (12,7 mm) to 1.250˝ (31,8 mm)
•
Convert raw-edged holes to smooth,
neat, insulated holes.
•
Retaining bead snaps securely
into place.
•
Insulate and mechanically protect
cable, tubing, hose, rope, rods,
and shafts.
•
UL approved for applications up to
122° F (50°C).
•
Six diameters fit panel thickness from
.03˝ (0,8 mm) to .08˝ (2,0 mm).
MOUNTING
HOLE
DIAMETER
in.
.500
.625
mm.
12,7
15,9
G1505
G1506
TG 500
TG 625
TG 750
TG 875
TG 1000
TG 1250
PART NO.
Black
DESCRIPTION
A
Inside
Diameter
in.
mm.
.41
.52
.65
.77
.89
1.12
10,4
13,2
16,5
19,6
22,6
28,4
PART DIMENSIONS
B
Head
Diameter
in.
mm.
.81
.93
1.06
1.19
1.32
1.60
20,6
23,6
26,9
30,2
33,5
40,6
C
Overall
Height
in.
.28
.31
mm.
7,1
7,9
.750
19.1
G1507
.875
22,2
G1508
1.000
25,4
G1509
1.250
31,8
G1510
Molded from Thermoplastic Rubber.
.35
8,9
Material
Certifications
MSB
6-9
Quick
Specs
Flammability Rating
Temperature Range
Material
Certifications
Temperature Range
TG
6/6 Nylon
Recognized under the Component Program of Underwriters’
Laboratories File E15331
Certified by the Canadian Standards Association File 8919
94V-2
-.4°F (-18°C) to 221°F (105°C)
Flex Temp (Thermoplastic Rubber)
Listed under Underwriters’ Laboratories File E15331
32°F (0°C) to 122°F (50°C)
