LGR
ALUMINUM ELECTROLYTIC CAPACITORS
Snap-in Terminal Type, 105°C Long Life Assurance
Long life assurance series withstanding 10000 hours
application of ripple current at 105°C.
Compliant of the RoHS directive (2011/65/EU).
LGR
Specifications
Item
Long Life
LGY
Performance Characteristics
Category
Temperature Range
Rated
Voltage Range
Rated
Capacitance Range
Capacitance Tolerance
Leakage Current
–
40 to +105°C (200
250V) ,
–
25 to +105°C (400
450
V)
200 to 450V
39 to 1500µF
3
CV
± 20% at 120Hz, 20°C
3 CV
I
3 CV (µA) (After 5 minutes' application of rated voltage)
[C : Rated Capacitance (µF) V : Voltage (V)]
Measurement frequency : 120Hz at 20°C
Rated voltage(V)
tan
δ
(MAX.)
Tangent of loss angle (tan
δ)
200 to 400
0.15
450
0.20
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Z
–
25°C/ Z+20°C
Impedance ratio
ZT/Z20 (MAX.)
Z
–
40°C/ Z+20°C
200
3
12
250
400
8
—
450
Endurance
The specifications listed at right shall be met when the
capacitors are restored to 20°C after D.C. bias plus rated
ripple current is applied for 10000 hours at 105°C, the
peak voltage shall not exceed the rated voltage.
After storing the capacitors under no load at 105°C for
1000 hours and then performing voltage treatment based
on JIS C 5101-4 clause 4.1 at 20°C,
they shall meet the requirements listed at right.
Printed with white color letter on black sleeve.
Capacitance change
tan
δ
Leakage current
Capacitance change
tan
δ
Leakage current
Within ± 25% of the initial capacitance value
250% or less than the initial specified value
Less than or equal to the initial specified value
Within ±15% of the initial capacitance value
150% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
Marking
Drawing
Polarity bar
Polarity bar
Sleeve (P.E.T.)
Sleeve (P.E.T.)
φD
+1.5 MAX.
φD
+1.5MAX.
Type numbering system (Example : 400V 120
µ
F)
1
2
1
3
2
4
3
5
4
6
5
7
6
8
7
9
8
9 10 11 12
13 14
10 11 12
13 14
GR
G
1 M
L GLR 2 G2 1 21 12 M E LE ZL Z 04 0
4
（
1
0
）
4.0±0.5
4.0±0.5
（
1
0
）
L
±2
L
±2
Pressure relief vent
Pressure relief vent
0.8
（2.5）
4.0±0.5
4.0±0.5
0.8
+0.2
-0.1
+0.2
-0.1
0
.2
+0 .1
.2
+0 .1
0.8
-0
0
.8
-
Case length code
Case length code
Case dia. code
Case dia. code
Configuration
φD
Code
Configuration
φD
Code
Capacitance tolerance (±20%)
22
Z
Capacitance tolerance (±20%)
22
Z
25
A
Rated capacitance (120µF) 25
A
Rated capacitance (120µF)
30
B
Rated voltage (400V) 30
B
Rated voltage (400V)
35
C
C
Series name 35
Series name
Type
Type
（2.5）
1.5
+0.2
1.5
-0.1
+0.2
-0.1
The other terminal is also available upon request.
Please refer page 332 for schematic of dimensions.
Frequency coefficient of rated ripple current
Frequency (Hz)
Coeff.
200
•
250V
400
•
450V
50
0.81
0.77
60
0.85
0.82
120
1.00
1.00
300
1.17
1.16
1k
1.32
1.30
10k
1.45
1.41
50k or more
1.50
1.43
Minimum order quantity : 50pcs.
Dimension table in next page.
315
