Heyco Nylon PCB Supports - Metric Spacing
®
TEARDROP SNAP LOCK /
TWO PRONG SNAP LOCK
WINGLESS ARROWHEAD LOCK /
WINGLESS ARROWHEAD LOCK
WINGLESS ARROWHEAD LOCK /
WINGLESS ARROWHEAD LOCK
WINGLESS ARROWHEAD LOCK /
WINGLESS ARROWHEAD LOCK
HSP-MDL-AH-1
Maximum
Thickness
in.
mm.
PCB
Chassis
A
mm.
2,0
3,0
4,0
5,0
6,0
7,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
22,0
.062
.062
1,6
1,6
Mounting
Hole Diameter
in.
mm.
.098
.098
2,5
2,5
HDLSP1
Maximum
Thickness
in.
mm.
.062
.062
1,6
1,6
Mounting
Hole Diameter
in.
mm.
.157
.157
4,0
4,0
HDLSP2
Maximum
Thickness
in.
mm.
.062
.062
1,6
1,6
Mounting
Hole Diameter
in.
mm.
.187
.187
4,8
4,8
HDLSP3
Maximum
Thickness
in.
mm.
.062
.062
1,6
1,6
Mounting
Hole Diameter
in.
mm.
.157
.187
4,0
4,8
PART NO.
Natural
10508
10509
10510
10511
10512
10513
10514
10515
10516
10517
10518
10519
10520
10521
DESCRIPTION
HSP-MDL-AH-1-02M
HSP-MDL-AH-1-03M
HSP-MDL-AH-1-04M
HSP-MDL-AH-1-05M
HSP-MDL-AH-1-06M
HSP-MDL-AH-1-07M
HSP-MDL-AH-1-08M
HSP-MDL-AH-1-10M
HSP-MDL-AH-1-12M
HSP-MDL-AH-1-14M
HSP-MDL-AH-1-16M
HSP-MDL-AH-1-18M
HSP-MDL-AH-1-20M
HSP-MDL-AH-1-22M
PART NO.
Natural
DESCRIPTION
PART NO.
Natural
DESCRIPTION
PART NO.
Natural
DESCRIPTION
10523
10524
10525
10526
10527
10528
10529
10530
10531
HDLSP1-03M
HDLSP1-04M
HDLSP1-06M
HDLSP1-08M
HDLSP1-10M
HDLSP1-12M
HDLSP1-14M
HDLSP1-16M
HDLSP1-18M
10533
10534
10535
10536
10537
10538
10539
10540
10541
HDLSP2-03M
HDLSP2-04M
HDLSP2-06M
HDLSP2-08M
HDLSP2-10M
HDLSP2-12M
HDLSP2-14M
HDLSP2-16M
HDLSP2-18M
10543
10544
10545
10546
10547
10548
10549
10550
10551
HDLSP3-03M
HDLSP3-04M
HDLSP3-06M
HDLSP3-08M
HDLSP3-10M
HDLSP3-12M
HDLSP3-14M
HDLSP3-16M
HDLSP3-18M
Standard color natural. For special order parts in UL 94V-0 natural material, add the suffix “F” to Part No.
Material
Flammability Rating
Temperature Range
Nylon 6/6
94V-2
.4°F (-18°C) to 185°F (85°C)
Quick
Specs
13
