TIMERS
P – PANEL MOUNTING ADAPTER
This panel adapter is a rugged, black, auto
extinguishable polycarbonate material. It is
mounted with two 6/32 screws. A timer is mounted
by clipping to the adapter or panel. Order
part number P ADAPT.
+
TIMERS
2.83"
(72 mm)
2.46"
(62.5 mm)
++
.39"
(10 mm)
2.36"
(60 mm)
DR – DIN-RAIL
The DR-DIN-Rail material is an extruded aluminum
material of the standard configuration, 35mm. Timers
and Controls conveniently snap onto the track. Order
part number “DR” which is available in 1 meter (39˝)
lengths. Shown with S08, S11 and K11 sockets.
S08, S11 & SCREW TERMINAL
SOCKETS
The S08, and S11 are 8 and 11 pin sockets
fabricated from a rugged, durable polycarbonate.*
The color is grey to match the majority of
accessories available. Mounting is with two 6/32
screws .250 or on .30 DIN-Rail, DR. Order part “S08”
or “S11.”
2.30"
.58"
1.42"
(36mm)
.315"
(8mm)
.165"
(4.19mm)
1.14"
(29mm)
BND DIN Rail
.200"
.320"
2.01"
.2.2"
(56mm)
ø .165"
2.99"
(76 mm)
+
+
2.06"
.82"
S11
S08-600:
600V, 10A rated 8 pin socket-UL and CSA
1.46"
.079" (37mm)
(2mm) 1.69"
(43mm)
.571"
(14.5mm)
.984"
(25mm)
S08
S12 & S15 SOLDER TERMINAL
SOCKETS
The S12 and S15 are 11 and 8 pin solder termi-
nal sockets fabricated from a rugged, durable
polycarbonate. They are black and connections
are made by soldering to the tabs or by 3/16˝
(4.8mm) push-on connectors. Order Part Number
“S12” (11 pin) and “S15” (8 pin)
1.89"
(48mm)
1.26"
(32mm)
.20"
(5.2mm)
1.50"
(38mm)
SA8 & SA11 - Back connecting Socket
1.77
18
58
1.77
18
58
SA11NN
SA8NN
Products and specifications subject to change without notice.
Order/Technical Support – Tel: (800) 677-5311 / FAX: (800) 677-3865 / www.crouzet-usa.com
2/54
+
++
+
.50"
(12.5 mm)
+
.86"
(22.5 mm)
.16"
(4.2 mm)
T
I
M
E
R
S
.980"
.1650"
1.295"
1.575"
.68"
(17.3mm)
.312"
1.77
1.77
TIMERS
TIMERS
SOCKETS
PC Board Sockets (mm)
ACCESSORIES FOR RTM TIMER
5
11.5
1.5
4.1
5.3
2x6.3
6.5
=
21.5
=
=
21.5
21.5
13.2
=
=
3x4.4
=
29.5
29.5
25.5
29.5
13.5
2 Poles
Ref:
26532709
30
24
4 Poles
Ref:
26532708
7.5
2
11
68
4.1
11
2 Poles
Ref:
26532707
4 Poles
Ref:
26532706
Mounting Clip for DIN-Rail Sockets
Ref:
26532702
RTM
79 238 250 (Part Number)
PANEL MOUNT REMOTE POTENTIOMETER
470K Ohm ±10% / 0.2 W / linearity ±10%
DIMENSIONS:
inches (mm)
.57˝
(14,5)
Panel
Screw
Ø1.14˝
(Ø29)
Sealing ring
1
➛
8mm
.87˝
(28)
Products and specifications subject to change without notice.
Order/Technical Support – Tel: (800) 677-5311 / FAX: (800) 677-3865 / www.crouzet-usa.com
2/55
.87˝
(Ø22)
