ABS1,4,5
HIGH ENVIRONMENTAL
RESISTANCE
VDE
TURQUOISE SWITCHES
ABS TYPE
FEATURES
19.3
11.1
6.4
• Subminiature size (19.8×11.1×6.4 mm)
• Sealed construction for use in adverse environment-Sealed construction by
epoxy resin and rubber cap greatly reduces possible miscontact due to
contaminants such as dust. Conforming to IP67* of IEC protective construction
classification
• Elastomer double molding technology, an industry first and ultrasonic swaging
technology contribute to uniform sealing in high production quantities
• Expansion of low-level circuit type
• We offer a Au clad 2-ply contact type (for small loads) that we developed
specifically for small current and voltage loads in the range of 1 mA to 100 mA
and 5 V to 30 V.
• UL/CSA/VDE/SEMKO approved
(AS for Au-clad twin layer, VDE and SEMKO are not approved.)
* Based on the protective construction classification of IEC, items which satisfy the test
requirements are denoted with an IP designation.
TYPICAL APPLICATIONS
http://panasonic-denko.co.jp/
ac/e/service/environment
• Automotive
• Home appliances (vacuum cleaner, air purifier)
• Others (gas cooking range)
ORDERING INFORMATION
Ex. ABS
1
1
1
0
4
0
3
Type of
switch
Wire
and
terminal
position
Terminal
Contact
arrangement
ABS:
1:
Straight
type 1: .110
quick-connect
Turquoise 4: Right
angle
terminal
switch
5: Left
angle
4:
Solder
terminal
S
type
5: PC
board
terminal
6: Wire leads
Operating
force
by
Actuator
Contact*
Agency
standard
pin plunger
(max.)
1:
SPDT
0: Pin plunger
4: 0.98 N
0: AgNi
alloy
3:
UL/CSA/VDE/SEMKO
2:
SPST-NC
1:
Short
hinge lever 5: 1.47 N
1: Au-clad
(AgNi
alloy
contact,
3: SPST-NO
2: Hinge lever
triple layer
Au-clad triple layer type)
3:
Long hinge lever
4: Au-clad
9: UL/CSA
4:
Simulated
roller
double layer
(Au-clad double layer type)
lever
6: Roller lever
8:
Leaf lever
Remarks: 1.
2.
3.
4.
Standard
packing: Dust protected type 100 pcs./carton, 1,000 pcs./case; Immersion protected type 50 pcs./case.
SPST-NC and SPST-NO are
only
available
for wire leads type.
Leaf lever is only
available
for wire leads type
As for wire position:
Straight
type
Wire opposite to the
actuator side
type
(Right
angle)
Wire
actuator side
type
(Left
angle)
5. Not every combination is
available.
Please refer to the following table,
“PRODUCT
TYPES”.
*
Contact
0: AgNi
alloy
AgNi
alloy
1: Au-clad triple layer
Au-clad
CuNi
alloy
AgNi
alloy
4: Au-clad double layer
Au-clad
CuNi
alloy
36
06/2009
