SHEET 1 OF 1
5.08
`
.10
[.200
`
.004
in]
TYP.
n
1.20
[.047 in]
P.C. MOUNTING
O.P. (MM)
D
P.T. (MM)
14.91
[.587 in]
5.60
[.220 in]
NC
P.T.
9.5
`
0.8
1.8 MAX.
O.P. = OPERATING POINT
P.T. = PRE-TRAVEL
ISOMETRIC
3.60
[.142 in]
COM
NO
CIRCUIT: SPDT
[
.083
2.10
- .10
.00
+.004
- .000
+
in
]
O.P.
6.50
[.256 in]
NOTES:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=
`
0.4
n
2.20
X.XX=
`
0.25
[.087 in]
3. RATING: 3A @125VAC UL, CSA APPROVED
1.50
4. TERM. NOS. FOR REF. ONLY
[.059 in]
5. OPERATING FORCE: 50
`
5 GRAMS
6. OPERATING TEMP: -25
~
C TO 85
~
C
.90
7. ELECTRICAL LIFE: 10,000 CYCLES MIN.
[.035 in]
8. MECHANICAL LIFE: 300,000 CYCLES MIN.
9. INSULATION RESISTANCE: 100 MEGA-OHMS
10. DIELECTRIC STRENGTH: 1000V RMS AT SEA LEVEL
11.
DENOTES CRITICAL PARAMETER.
12. 2002/95/EC (ROHS) COMPLIANT
123 CONTACT MATERIAL SILVER
[.081 in]
n
2.05
3.50
[.138 in]
6.50
[.256 in]
5.08
[.200 in]
5.08
[.200 in]
.60
[.024 in]
5.85
[.230 in]
12.80
`
.15
[.504
`
.006
in]
D
C
REV
20204
17472
PCR NO
UPDATE DRAWING
REVISED AND REDRAWN
DESCRIPTION
10/11/11
7/16/07
DATE
BMA
BF
BY
TITLE
SCALE
DM0850302F050P1A
4:1
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
7/16/2007
DR
BF
DWG
P030014
REV
D
