L0603B100MPWFT Overview

Fixed Inductors V

L0603B100MPWFT Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	KEMET
package instruction	0603
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	79 weeks
Samacsys Description	Fixed Inductors 0603 10uH 20% 200mAmps
uppercase and lowercase codes	0603
structure	Wirewound Chip
core material	Ferrite
DC Resistance	1.2 Ω
Nominal inductance(L)	10 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e3
Number of functions	1
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Package height	0.8 mm
Package length	1.6 mm
Package form	SMT
Package width	0.8 mm
method of packing	TR
Maximum rated current	0.2 A
self resonant frequency	40 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
special characteristics	DCR MEASURED AT 30% TOLERANCE
surface mount	YES
Terminal surface	Matte Tin (Sn)
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	2.52 MHz
Tolerance	20%

Preview

Download Datasheet

View All

Surface Mount

Ferrite Products

Inductors & Ferrite Beads

www.kemet.com

F3115D 1/08

Table of Contents

L-Wire Wound Chip Inductors - L-PW Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4

0805 Case Size Standard Type (L-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5

0806 Case Size Standard Type (L-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5

1007 Case Size Standard Type (L-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5

1207 Case Size Standard Type (L-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 6

0603 Case Size Standard Type (L-PWF Series Bottom Surface Electrode) . . . . . . . . . . . . . . . . . . . . . . . Page 6

0805 Case Size High Current Type (L-PWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 6

0806 Case Size High Current Type (L-PWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 6

1007 Case Size High Current Type (L-PWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 7

0805 Case Size Low Rdc Type (L-PWR Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 7

1007 Case Size Low Rdc Type (L-PWR Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 7

L-Wire Wound Chip Inductors - L-DWS/L-DWI/L-DWL Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 8

0805 Case Size Low Rdc Type (L-DWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9

0806 Case Size Low Rdc Type (L-DWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9

1007 Case Size Low Rdc Type (L-DWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9

0805 Case Size High Current Type (L-DWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9

0806 Case Size High Current Type (L-DWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9

1007 Case Size High Current Type (L-DWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 10

1210 Case Size High Current Type (L-DWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 10

0805 Case Size Low Profile Type (L-DWL Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 10

0603 Case Size Power, Bottom Surface Electrode Type (L-DWF Series) . . . . . . . . . . . . . . . . . . . . . . . . Page 10

L-Multilayer Chip Inductors for High Frequency - L-RMS Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 11

0201 Case Size Multilayer Chip Inductors for High Frequency (RMS Series) . . . . . . . . . . . . . . . . . . . . . Page 12

0402 Case Size Multilayer Chip Inductors for High Frequency (RMS Series) . . . . . . . . . . . . . . . . . . . . . Page 13

0603 Case Size Multilayer Chip Inductors for High Frequency (RMS Series) . . . . . . . . . . . . . . . . . . . . . Page 14

0805 Case Size Multilayer Chip Inductors for High Frequency (RMS Series) . . . . . . . . . . . . . . . . . . . . . Page 15

L-Multilayer Chip Inductors - L-SMS/L-PMS/L-DMI Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 16

0402 Case Size Multilayer Chip Inductors (L-SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 17

0603 Case Size Multilayer Chip Inductors (L-SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 18

0805 Case Size Multilayer Chip Inductors (L-SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 19

0603 Case Size Multilayer Chip Inductors (L-PMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 20

0805 Case Size Multilayer Chip Inductors (L-PMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 20

1008 Case Size Multilayer Chip Inductors (L-DMI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 20

L-Low Profile SMD Inductors (L-DWD Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 21

L-DWD3010 Type (1.0mm Max. Height) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 21

L-DWD4010 Type (1.0mm Max. Height) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 21

L-DWD4012 Type (1.2mm Max. Height) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 22

L-DWD4018 Type (1.8mm Max. Height) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 22

L-DWD8040 Type (4.2mm Max. Height) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 22

Z-High Current Ferrite Chip Beads - Z-PWS/Z-PWZ Series. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 23

0603 Case Size High Current Ferrite Chip Beads (Z-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 24

0805 Case Size High Current Ferrite Chip Beads (Z-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 24

1206 Case Size High Current Ferrite Chip Beads (Z-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 24

1806 Case Size High Current Ferrite Chip Beads (Z-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 24

0603-1812 High Impedence Type Ferrite Chip Beads (Z-PWZ Series) . . . . . . . . . . . . . . . . . . . . . . . . . . Page 25

Z-Multilayer Ferrite Chip Beads - Z-SMS/Z-PMS Series. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 26

0201 Multilayer Ferrite Chip Beads Standard Type (SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 27

0402 Multilayer Ferrite Chip Beads Standard Type (SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 27

0402 Multilayer Ferrite Chip Beads for Power Lines (PMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 27

0603 Multilayer Ferrite Chip Beads Standard Type (SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 28

0603 Multilayer Ferrite Chip Beads for Power Lines (PMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 28

0805 Multilayer Ferrite Chip Beads Standard Type (SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 29

0805 Multilayer Ferrite Chip Beads for Power Lines (PMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 29

L0603B100MPWFT Related Products

	L0603B100MPWFT	L0603B220KPWFT	L0603B470MPWFT	L0603B220MPWFT
Description	Fixed Inductors V	Fixed Inductors 22uH 10%	Fixed Inductors V	Fixed Inductors VC
Is it Rohs certified?	conform to	conform to	conform to	conform to
package instruction	0603	0603	0603	0603
Reach Compliance Code	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99
Factory Lead Time	79 weeks	79 weeks	79 weeks	79 weeks
uppercase and lowercase codes	0603	0603	0603	0603
structure	Wirewound Chip	Wirewound Chip	Wirewound Chip	Wirewound Chip
core material	Ferrite	Ferrite	Ferrite	Ferrite
DC Resistance	1.2 Ω	3.7 Ω	5.8 Ω	3.7 Ω
Nominal inductance(L)	10 µH	22 µH	47 µH	22 µH
Inductor Applications	RF INDUCTOR	RF INDUCTOR	RF INDUCTOR	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR
JESD-609 code	e3	e3	e3	e3
Number of functions	1	1	1	1
Number of terminals	2	2	2	2
Maximum operating temperature	105 °C	105 °C	105 °C	105 °C
Minimum operating temperature	-40 °C	-25 °C	-25 °C	-25 °C
Package height	0.8 mm	0.8 mm	0.8 mm	0.8 mm
Package length	1.6 mm	1.6 mm	1.6 mm	1.6 mm
Package form	SMT	SMT	SMT	SMT
Package width	0.8 mm	0.8 mm	0.8 mm	0.8 mm
method of packing	TR	TR	TR	TR
Maximum rated current	0.2 A	0.13 A	0.09 A	0.13 A
self resonant frequency	40 MHz	16 MHz	11 MHz	16 MHz
Shape/Size Description	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
shield	NO	NO	NO	NO
special characteristics	DCR MEASURED AT 30% TOLERANCE	DCR MEASURED AT 30% TOLERANCE	DCR MEASURED AT 30% TOLERANCE	DCR MEASURED AT 30% TOLERANCE
surface mount	YES	YES	YES	YES
Terminal surface	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)
Terminal location	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED
Terminal shape	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND
Test frequency	2.52 MHz	2.52 MHz	2.52 MHz	2.52 MHz
Tolerance	20%	10%	20%	20%
