RT25
www.vishay.com
Vishay Sfernice
Wirewound Rheostat / Potentiometer
FEATURES
• 25 W at 25 °C
• CCTU 05-03B (PA1)
• Vitreous - RT style
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
DIMENSIONS
in millimeters
ADAPTATION BOARD
PANEL CUT OUT DETAILS
Ø 10.5
2 holes Ø 5
7.6
RT25-PA1
38
25
4
-0
Ø 6 - 0.05
23.5
23.5
M10 x 0.75
PANEL CUT OUT DETAILS
Ø 4.5
23
12.5 ± 0.5
Ø 2.2
9±1
12
60°
28
22 ± 2
AS
Ø 10.5
MOUNTING SIDE
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
RT25
RESISTANCE
RANGE
1 to 4.7K
TOLERANCE
±%
10
RATED POWER
P
25 °C
W
25
VARIATION LAW
STANDARD
(1)
Linear
LIMITING
ELEMENT VOLTAGE
V
300
DIELECTRIC
STRENGTH
V
RMS
1000
INSULATION
RESISTANCE
10
3
M (500 V
CC
)
Note
(1)
On request: sectorial winding
CLIMATIC SPECIFICATIONS
Temperature range
Climatic category
-55 °C; +320 °C
CCTU 454
CEI 55 / 200 / 56
MECHANICAL SPECIFICATIONS
Mechanical protection
Mechanical travel
Operating torque
End stop torque
Unit weight
Vitreous
300° ± 5°
1 Ncm to 10 Ncm
50 Ncm
80 g
Revision: 24-Aug-16
Document Number: 50026
1
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
RT25
www.vishay.com
LOCKING DEVICE
This is supplied as an option.
The available spindle length is according to the panel
thickness.
Order reference: DBA6
1 ± 0.2
13
2 tightening screws
Vishay Sfernice
PARTICULAR CHARACTERISTICS
NOMINAL
RESISTANCE
1
1.5
2.2
3.3
4.7
MAX. SERVICE
VOLTAGE
V
5
6.12
7.42
9.08
10.8
13
15.8
19.4
23.5
28.7
34.3
41.2
50
61.2
74.2
90.8
108
130
158
194
235
287
343
MAX. CURRENT
THROUGH WIPER
mA
5000
4080
3370
2750
2300
1920
1580
1290
1070
870
730
605
500
408
337
275
230
192
158
129
107
87
73
spanner n° 14
max. panel thickness 6.5
6.8
10
15
22
ADAPTATION BOARD
This enables 2 point mounting instead of bush mounting.
The adaptation board is supplied as an option with 2
mounting screws. Consequently, the available spindle
length is reduced by 9.5 mm.
33
47
68
100
150
SPINDLES
Ø
mm
DISTANCE TO
MOUNTING
PLATE mm
22
6
25
With
50
6
22
Without
Without
AMF
AL
AS
SCREW
DRIVER
SLOT
With
Without
CODE
ASF
AM
220
330
470
680
1K
1.5K
2.2K
3.3K
4.7K
Note
• For any special requirement on request: spindle flats, etc. Please
supply detailed drawing.
COMMAND SHAFT 29JF (OPTION)
18
DIAL CG57 (OPTION)
4 holes Ø 3.5
5
6
7
8
1
0
47
56
10
9
47 56
Ø 43
Ø7
21
Ø 12
2
4
3
MARKING
Vishay Sfernice trademark, series, style, power rating in watts, ohmic value (in
or k), tolerance (in %), maximum current in
A, manufacturing date.
Revision: 24-Aug-16
Document Number: 50026
2
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
RT25
www.vishay.com
Vishay Sfernice
ORDERING INFORMATION
RT
MODEL
025
STYLE
ASF
SPINDLE
2201
OHMIC VALUE
K
TOLERANCE
B
PACKAGING
XXX
SPECIAL DESIGN
GLOBAL PART NUMBER INFORMATION
R
T
0
2
5
A
S
1
0
R
0
K
B
GLOBAL
SIZE
MODEL
RT
025
LOCKING
DEVICE (OPT.)
D
WINDING
(OPT.)
BXXX
or
BXXXX
COMMAND
SHAFT
OHMIC VALUE
TOLERANCE PACKAGING
J
=5%
K
= 10 %
B
= bulk
BO10
No standard
packaging:
N
= bulk,
qty. open
SPECIAL
As applicable
Ex
= DXxx
The three first digits are
AS
= standard
significant figures and the
(Diam: 6 mm)
last digit specifies the
AM
number of zeros to follow.
AMF
R designates decimal point.
AL
As applicable
ASF
xxx(x) =
2002
= 20 k
internal
4700
= 470
number
10R0
= 10
0R01
= 0.01
RELATED DOCUMENTS
APPLICATION NOTES
Potentiometers and Trimmers
Guidelines for Vishay Sfernice Resistive and Inductive Components
www.vishay.com/doc?51001
www.vishay.com/doc?52029
Revision: 24-Aug-16
Document Number: 50026
3
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
