CM6296R
CM6296
CE
AN )
CT (µH
DU L
IN A
E PIC
AG TY
AK
T
LE
EN
RR UM
CU M
S AXI
RM M
D S)
TE MP
RA (A
CE
AN )
ST S
SI HM
RE M (O
DC MU
XI
MA
CE
AN )
CT (µH
DU %
IN 25
L2 ±
or
L1
rm
fo
ns
DA
SH
NU
Common Mode
Choke/IsolationTransformer
er
E
MB
R*
Actual Size
s
-253
-503
-104
-154
-204
-304
-454
-654
-105
-155
-255
SERIES CM6296 FERRITE CORE
25
0.014
10.0
50
0.014
10.0
100
0.016
9.5
150
0.016
9.5
200
0.016
8.5
300
0.020
7.5
450
0.024
6.5
650
0.030
5.5
1000
0.050
3.5
1500
0.090
2.5
2500
0.162
2.2
0.7
0.8
1.4
1.8
2.2
3.3
4.6
6.2
9.3
14.5
21.8
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
Physical Parameters
Inches
A
1.058 ± 0.010
B
0.870 ± 0.010
C
0.210 Typ.
D
0.200 Typ.
E
0.430 Max.
Millimeters
26.87 ± 0.25
22.10 ± 0.25
5.33 Typ.
5.08 Typ.
10.74 Max.
Mechanical Configuration
Flat top surface mount case
with excellent coplanarity of terminals
Operating Temperature
–55°C to +125°C
Configuration
Two inductors per unit; internal terminals:
#1 (start)-#2 (finish) & #4 (start) -#3 (finish)
Electrical Configuration
1) Inductance and DCR in table is for either L1 or L2
2) Leakage Inductance tested at L1 with L2 shorted or at
L2 with L1 shorted.
3) Windings balanced within 2%
4) Inductance tested @ 1.0kHz
Rated RMS Current Per Winding
Based Upon 20°C
temperature rise from 25°C ambient
Maximum Power Dissipation at 25°C
2.5 Watts
Dielectric Withstanding Voltage
500 V RMS, 60Hz
Marking
DELEVAN; part number, inductance with units. A white dot
indicates the location of pin 1.
Example: CM6296R-155
DELEVAN
CM6296R-155
1500 uH
Packaging
Bulk only
Weight (Grams)
9.0 (Ref.)
