L0402CR18KSMST Overview

Fixed Inductors VC

L0402CR18KSMST Parametric

Parameter Name	Attribute value
Product Category	Fixed Inductors
Manufacturer	KEMET
Inductance	0.18 uH
Tolerance	10 %
Maximum DC Current	25 mA
Maximum DC Resistance	1.1 Ohms
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Product	Power Inductors
Shielding	Shielded
Termination Style	SMD/SMT
Termination	-
Package / Case	0402 (1005 metric)
Length	1 mm
Width	0.5 mm
Height	0.5 mm
Packaging	Reel
Case Code - in	0402
Case Code - mm	1005
Core Material	Ceramic
Mounting Style	SMD/SMT
Q Minimum	10
Self Resonant Frequency	150 MHz
Factory Pack Quantity	10000
Test Frequency	25 MHz
Type	Chip Inductors
Unit Weight	0.000023 oz

Preview

Download Datasheet

View All

Surface Mount

Ferrite Products

Inductors & Ferrite Beads

www.kemet.com

F3115D 1/08

Table of Contents

L-Wire Wound Chip Inductors - L-PW Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4

0805 Case Size Standard Type (L-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5

0806 Case Size Standard Type (L-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5

1007 Case Size Standard Type (L-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5

1207 Case Size Standard Type (L-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 6

0603 Case Size Standard Type (L-PWF Series Bottom Surface Electrode) . . . . . . . . . . . . . . . . . . . . . . . Page 6

0805 Case Size High Current Type (L-PWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 6

0806 Case Size High Current Type (L-PWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 6

1007 Case Size High Current Type (L-PWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 7

0805 Case Size Low Rdc Type (L-PWR Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 7

1007 Case Size Low Rdc Type (L-PWR Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 7

L-Wire Wound Chip Inductors - L-DWS/L-DWI/L-DWL Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 8

0805 Case Size Low Rdc Type (L-DWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9

0806 Case Size Low Rdc Type (L-DWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9

1007 Case Size Low Rdc Type (L-DWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9

0805 Case Size High Current Type (L-DWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9

0806 Case Size High Current Type (L-DWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9

1007 Case Size High Current Type (L-DWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 10

1210 Case Size High Current Type (L-DWI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 10

0805 Case Size Low Profile Type (L-DWL Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 10

0603 Case Size Power, Bottom Surface Electrode Type (L-DWF Series) . . . . . . . . . . . . . . . . . . . . . . . . Page 10

L-Multilayer Chip Inductors for High Frequency - L-RMS Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 11

0201 Case Size Multilayer Chip Inductors for High Frequency (RMS Series) . . . . . . . . . . . . . . . . . . . . . Page 12

0402 Case Size Multilayer Chip Inductors for High Frequency (RMS Series) . . . . . . . . . . . . . . . . . . . . . Page 13

0603 Case Size Multilayer Chip Inductors for High Frequency (RMS Series) . . . . . . . . . . . . . . . . . . . . . Page 14

0805 Case Size Multilayer Chip Inductors for High Frequency (RMS Series) . . . . . . . . . . . . . . . . . . . . . Page 15

L-Multilayer Chip Inductors - L-SMS/L-PMS/L-DMI Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 16

0402 Case Size Multilayer Chip Inductors (L-SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 17

0603 Case Size Multilayer Chip Inductors (L-SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 18

0805 Case Size Multilayer Chip Inductors (L-SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 19

0603 Case Size Multilayer Chip Inductors (L-PMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 20

0805 Case Size Multilayer Chip Inductors (L-PMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 20

1008 Case Size Multilayer Chip Inductors (L-DMI Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 20

L-Low Profile SMD Inductors (L-DWD Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 21

L-DWD3010 Type (1.0mm Max. Height) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 21

L-DWD4010 Type (1.0mm Max. Height) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 21

L-DWD4012 Type (1.2mm Max. Height) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 22

L-DWD4018 Type (1.8mm Max. Height) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 22

L-DWD8040 Type (4.2mm Max. Height) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 22

Z-High Current Ferrite Chip Beads - Z-PWS/Z-PWZ Series. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 23

0603 Case Size High Current Ferrite Chip Beads (Z-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 24

0805 Case Size High Current Ferrite Chip Beads (Z-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 24

1206 Case Size High Current Ferrite Chip Beads (Z-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 24

1806 Case Size High Current Ferrite Chip Beads (Z-PWS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 24

0603-1812 High Impedence Type Ferrite Chip Beads (Z-PWZ Series) . . . . . . . . . . . . . . . . . . . . . . . . . . Page 25

Z-Multilayer Ferrite Chip Beads - Z-SMS/Z-PMS Series. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 26

0201 Multilayer Ferrite Chip Beads Standard Type (SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 27

0402 Multilayer Ferrite Chip Beads Standard Type (SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 27

0402 Multilayer Ferrite Chip Beads for Power Lines (PMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 27

0603 Multilayer Ferrite Chip Beads Standard Type (SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 28

0603 Multilayer Ferrite Chip Beads for Power Lines (PMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 28

0805 Multilayer Ferrite Chip Beads Standard Type (SMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 29

0805 Multilayer Ferrite Chip Beads for Power Lines (PMS Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 29
