GBU6A THRU GBU6M
GLASS PASSIVATED SINGLE-PHASE BRIDGE RECTIFIER
Reverse Voltage -
50 to 1000 Volts
Forward Current -
6.0 Amperes
FEATURES
Case Style GBU
0.880 (22.3)
0.020 R (TYP.)
0.860 (21.8)
0.125 (3.2) x 45
o
CHAMFER
0.310 (7.9)
0.290 (7.4)
0.160 (4.1)
0.140 (3.5)
0.740 (18.8)
0.720 (18.3)
0.085 (2.16)
0.065 (1.65)
0.075
(1.9) R.
0.080 (2.03)
0.060 (1.52)
0.140 (3.56)
0.130 (3.30)
9
o
TYP.
5
o
TYP.
0.085 (2.16)
0.710 (18.0)
0.690 (17.5)
0.100 (2.54)
0.085 (2.16)
0.050 (1.27)
0.040 (1.02)
0.075 (1.90)
♦
Plastic package has Underwriters Laboratory Flammability
Classification 94V-0
♦
This series is UL listed under the Recognized Component
Index, file number E54214
♦
High case dielectric
strength of 1500 V
RMS
♦
Ideal for printed circuit boards
♦
Glass passivated chip junctions
♦
High surge overload rating
♦
High temperature soldering guaranteed:
260°C/10 seconds, 0.375" (9.5mm) lead length,
5lbs. (2.3kg) tension
0.080 (2.03)
0.065 (1.65)
0.190 (4.83)
0.210 (5.33)
0.022 (0.56)
0.018 (0.46)
MECHANICAL DATA
Case:
Molded plastic body over passivated chip
Terminals:
Plated leads solderable per MIL-STD-750,
Method 2026
Mounting Position:
Any
(NOTE 2)
Mounting Torque:
5 in. - lb. max.
Weight:
0.15 ounce, 4.0 grams
Polarity shown on front side of case, positive lead by beveled corner
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
SYMBOLS
GBU
6A
GBU
6B
GBU
6D
GBU
6G
GBU
6J
GBU
6K
GBU
6M
UNITS
Maximum repetitive peak reverse voltage
Maximum RMS Voltage
Maximum DC blocking voltage
Maximum average forward rectified
output current at T
C
=100°C
(NOTE 1, 2)
Peak forward surge current single sine-wave
superimposed on rated load (JEDEC Method) T
J
=150°C
Rating for fusing (t<8.3ms)
Maximum instantaneous forward voltage drop
per leg at 6.0A
Maximum DC reverse current at
rated DC blocking voltage per leg
Typical thermal resistance per leg
(NOTE 1, 2)
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
t
V
F
I
R
C
J
R
ΘJA
R
ΘJC
T
J
, T
STG
50
35
50
100
70
100
200
140
200
400
280
400
6.0
175.0
127.0
1.0
5.0
500.0
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amps
Amps
A
2
sec
Volts
µA
T
A
=25°C
T
A
=125°C
Typical junction capacitance per leg
(NOTE 3)
211.0
7.4
2.2
-55 to +150
94.0
pF
°C/W
°C
Operating junction and storage temperature range
NOTES:
(1) Units case mounted on 2.6 x 1.4 x 0.06" thick (6.5 x 3.5 x 0.15 cm) Al. Plate heatsink
(2) Recommended mounting position is to bolt down on heatsink with silicone thermal compound for maximum heat transfer with #6 screws
(3) Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts
4/98
RATINGS AND CHARACTERISTICS CURVES GBU6A THRU GBU6M
FIG. 1 - DERATING CURVE OUTPUT RECTIFIED
CURRENT
PEAK FORWARD SURGE CURRENT,
AMPERES
FIG. 2 - MAXIMUM NON-REPETITIVE PEAK FORWARD
SURGE CURRENT PER LEG
AVERAGE FORWARD OUTPUT CURRENT,
AMPERES
6.0
HEAT-SINK MOUNTING,
2.6 x 1.4 x 0.06” THK
(6.5” x 3.5” x .15cm)
AL. PLATE
175
150
125
100
75
50
1.0 CYCLE
SINGLE SINE-WAVE
(JEDEC Method)
T
J
=150°C
4.0
2.0
60 H
Z
RESISTIVE OR INDUCTIVE LOAD
0
0
50
100
150
25
1
10
NUMBER OF CYCLES AT 60 H
Z
100
CASE TEMPERATURE, °C
FIG. 3 - TYPICAL FORWARD CHARACTERISTICS
PER LEG
100
FIG. 4 - TYPICAL REVERSE LEAKAGE
CHARACTERISTICS PER LEG
INSTANTANEOUS FORWARD CURRENT,
AMPERES
10
T
J
=25°C
PULSE WIDTH=300µs
1% DUTY CYCLE
INSTANTANEOUS REVERSE CURRENT,
MICROAMPERES
100
T
J
=125°C
10
1
1
0.1
0.1
T
J
=25°C
0.01
0.4
0.6
0.8
1.0
1.2
1.4
1.6
0.01
0
50 - 400V
600 - 1000V
20
40
60
80
100
INSTANTANEOUS FORWARD VOLTAGE,
VOLTS
PERCENT OF RATED PEAK REVERSE
VOLTAGE, %
FIG. 5 - TYPICAL JUNCTION CAPACITANCE
PER LEG
FIG. 6 - TYPICAL TRANSIENT THERMAL
IMPEDANCE
1,000
JUNCTION CAPACITANCE, pF
T
J
=25°C
f=1.0 MHz
Vsig=50mVp-p
100
TRANSIENT THERMAL IMPEDANCE,
°C\W
10
100
1
50 - 400V
600 - 1000V
10
0.1
1
10
100
0.1
0.01
0.1
1
t, HEATING TIME, sec.
10
100
REVERSE VOLTAGE, VOLTS
