NOTES:
1. DIMENSIONS ARE IN INCHES. DIMENSIONS IN BRACKETS
ARE MILLIMETERS.
2. UL LISTED & UL LISTED FOR USE IN CANADA.
D DIA
C
3. DUAL RATED CU9AL FOR ALUMINUM OR COPPER CONDUCTORS
(LIAC4-22-C, LIAS1/0-14-L, & LIAS250-56-Q ONLY).
4. RATED FOR DIRECT BURIAL APPLICATIONS
(LICC4-22-C & LICC4-22TP-C ONLY).
E
5. ANTI-OXIDANT JOINT COMPOUND RECOMMENDED.
6. PACKAGE QTY:
Q = 25
L = 50
C = 100
B
C
ANTI-ROTATIONAL
SERRATIONS
A
US
DB
RATED
(LICC4-22-C, LICC4-22TP-C ONLY)
DIMENSIONS ‐ IN [mm] +/‐ .02 [.5]
PANDUIT PART
NUMBER
MATERIAL
WIRE
RANGE
SCREW TYPE
A
B
C
STUD HOLE
D DIA
#12
.22 [5.6]
#12
.22 [5.6]
#12
.22 [5.6]
1/4"
.27 [6.9]
5/16"
.33 [8.4]
E
TIGHTENING
TORQUE
PKG.
QTY.
LICC4‐22‐C
LICC4‐22TP‐C
LIAC4‐22‐C
LIAS1/0‐14‐L
COPPER
COPPER, TIN PLATED
ALUMINUM, TIN PLATED
ALUMINUM, TIN PLATED
14 ‐ 4 CU AWG
14 ‐ 4 CU AWG
14 ‐ 4 CU/AL AWG
14 ‐ 1/0 CU/AL AWG
1/4‐28 SLOTTED
STAINLESS STEEL
1/4‐28 SLOTTED
STAINLESS STEEL
1/4‐28 SLOTTED
STAINLESS STEEL
3/8‐24 SLOTTED
STEEL, ZINC PLATED
1/2‐18 W/ 1/4" HEX KEY
STEEL, ZINC PLATED
1.16 [29.5] .87 [22.1]
1.16 [29.5] .87 [22.1]
1.06 [26.9] .78 [19.8]
.39 [9.9]
.39 [9.9]
.39 [9.9]
.19 [4.7]
.19 [4.7]
.19 [4.7]
.30 [7.6]
#14 ‐ #10 = 20 IN‐LB
#8 = 25 IN‐LB
#6 ‐ #4 = 35 IN‐LB
#14 ‐ #10 = 35 IN‐LB
#8 = 40 IN‐LB
#6 ‐ #4 = 45 IN‐LB
#3 ‐ #1/0 = 50 IN‐LB
200 IN‐LB
100
100
100
50
1.50 [38.1] 1.10 [27.9] .61 [15.5]
LIAS250‐56‐Q*
ALUMINUM, TIN PLATED
6 ‐ 250 kcmi l
CU/AL AWG
2.20 [55.9] 1.70 [43.2] .80 [20.3]
.40 [10.2]
25
* UL PENDING
10J018AY-JC/01B
CORP.
02
01
00
REV
TINLEY PARK, ILLINOIS
COPPER & ALUMINUM LAY-IN LUG CONNECTORS
CUSTOMER DRAWING
7/11
7/11
2/11
DATE
JHNU RGB
JHNU RGB
JHNU RGB
BY
CHK
REVISED PART NUMBER: LIAS1/0-14-L WAS LIAS10-14-L
REVISED WIRE RANGE: 14-4 WAS 4-14
REVISED DIMENSIONS FOR LICC4-22, LICC4-22TP: A WAS 1.09,
B WAS .75
REVISED NOTE 2, ADDED UL PENDING NOTE FOR LIAS250-56
10J018AY-JC
10J018AY-JC
10J018AY-JC
ECN
RGB RGB
RGB RGB
FLD
-R
UNLESS OTHERWISE SPECIFIED
DIMENSIONAL TOLERANCES ARE:
(.X)
(.XXX)
(.XX)
.02 [.5]
ANGLES
DRAWN BY
DATE
CHK'D
1
UNLESS OTHERWISE SPECIFIED,
ALL DIMENSIONS ARE GIVEN IN
INCHES, THIRD ANGLE PROJECTION
JHNU
2/11
RGB
MAT'L:
SCALE
NONE
DWG
RELEASED TO PRODUCTION
DESCRIPTION
FLD
SUP
SEE NOTES
DRAWING NO / CAD FILE
10J018AY-JC
B
SIZE
