DTB743Z series
PNP -200mA -30V Digital Transistors
(Bias Resistor Built-in Transistors)
Datasheet
lOutline
Parameter
Value
VMT3
OUT
IN
GND
IN
GND
EMT3
OUT
V
CC
I
C(MAX.)
R
1
R
2
lFeatures
-30V
-200mA
4.7kW
47kW
DTB743ZM
(SC-105AA)
DTB743ZE
SOT-416 (SC-75A)
lInner
circuit
1) Built-In Biasing Resistors
2) Built-in bias resistors enable the configuration of
an inverter circuit without connecting external
input resistors (see inner circuit).
3) The bias resistors consist of thin-film resistors
with complete isolation to allow negative biasing
of the input. They also have the advantage of
completely eliminating parasitic effects.
4) Only the on/off conditions need to be set for
operation, making the circuit design easy.
5) Complementary NPN Types :DTD743Z series
6) Lead Free/RoHS Compliant.
lApplication
Switching circuit, Inverter circuit, Interface circuit,
Driver circuit
lPackaging
specifications
Part No.
DTB743ZM
DTB743ZE
Package
VMT3
EMT3
Package
size
(mm)
1212
1616
Taping
code
T2L
TL
Basic
Reel size Tape width
ordering
(mm)
(mm)
unit (pcs)
180
180
8
8
8,000
3,000
Marking
Y13
Y13
www.rohm.com
© 2012 ROHM Co., Ltd. All rights reserved.
1/6
2012.07 - Rev.B
DTB743Z series
lAbsolute
maximum ratings
(Ta = 25°C)
Parameter
Supply voltage
Input voltage
Collector current
Power dissipation
Junction temperature
Range of storage temperature
Symbol
V
CC
V
IN
I
C(MAX.)*1
P
D *2
T
j
T
stg
Values
-30
-20
to
+5
-200
150
150
-55
to
+150
Data Sheet
Unit
V
V
mA
mW
°C
°C
lElectrical
characteristics(Ta
= 25°C)
Parameter
Input voltage
Output voltage
Input current
Output current
DC current gain
Input resistance
Resistance ratio
Transition frequency
Symbol
V
I(off)
V
I(on)
V
O(on)
I
I
I
O(off)
G
I
R
1
R
2
/R
1
f
T *1
Conditions
V
CC
=
-5V,
I
O
=
-100mA
V
O
=
-0.3V,
I
O
=
-20mA
I
O
/ I
I
=
-50mA
/
-2.5mA
V
I
=
-5V
V
CC
=
-30V,
V
I
= 0V
V
O
=
-2V,
I
O
=
-100mA
-
-
V
CE
=
-10V,
I
E
= 5mA,
f = 100MHz
Min.
-
-1.2
-
-
-
140
3.29
8
-
Typ.
-
-
-0.07
-
-
-
4.7
10
260
Max.
-0.3
-
-0.3
-1.4
-0.5
-
6.11
12
-
Unit
V
V
mA
mA
-
kW
-
MHz
*1 Characteristics of built-in transistor
*2 Each terminal mounted on a reference footprint
www.rohm.com
© 2012 ROHM Co., Ltd. All rights reserved.
2/6
2012.07 - Rev.B
DTB743Z series
lElectrical
characteristic curves(Ta
= 25°C)
Data Sheet
Fig.1 Input voltage vs. output current
(ON characteristics)
Fig.2 Output current vs. input voltage
(OFF characteristics)
OUTPUT CURRENT : I
O
[mA]
OUTPUT CURRENT : I
O
[mA]
INPUT VOLTAGE : V
I(on)
[V]
INPUT VOLTAGE : V
I(off)
[V]
Fig.3 Output current vs. output voltage
-200
-0.9mA -0.8mA
I
I
=
-1.0mA
-0.7mA -0.6mA
-0.5mA
-0.4mA
Fig.4 DC current gain vs. output current
OUTPUT CURRENT : I
O
[mA]
-0.3mA
-100
-0.2mA
-50
-0.1mA
Ta=25ºC
0
0
-5
0A
-10
DC CURRENT GAIN : G
I
-150
OUTPUT VOLTAGE : V
O
[V]
OUTPUT CURRENT : I
O
[mA]
www.rohm.com
© 2012 ROHM Co., Ltd. All rights reserved.
3/6
2012.07 - Rev.B
DTB743Z series
lElectrical
characteristic curves(Ta
= 25°C)
Data Sheet
Fig.5 Output voltage vs. output current
OUTPUT VOLTAGE : V
O(on)
[V]
OUTPUT CURRENT : I
O
[mA]
www.rohm.com
© 2012 ROHM Co., Ltd. All rights reserved.
4/6
2012.07 - Rev.B
DTB743Z series
lDimensions
(Unit : mm)
D
b1
c
Data Sheet
VMT3
A
L
e
b
H
E
x
S A
b3
l1
Lp
A
A1
S
l1
b2
e
Patterm of terminal position areas
DIM
A
A1
b
b1
c
D
E
e
H
E
L
Lp
x
DIM
e1
b2
b3
l1
MILIMETERS
MIN
MAX
0.45
0.55
0.00
0.10
0.17
0.27
0.27
0.37
0.08
0.18
1.10
1.30
0.70
0.90
0.40
1.10
1.30
0.10
0.30
0.20
0.40
-
0.10
MILIMETERS
MIN
MAX
0.80
-
0.37
-
0.47
-
0.50
INCHES
MIN
0.018
0
0.007
0.011
0.003
0.043
0.028
0.02
0.043
0.004
0.008
-
INCHES
MIN
0.03
-
-
-
0.015
0.019
0.02
MAX
0.051
-
-
0.004
MAX
0.022
0.004
0.011
0.015
0.007
0.051
0.035
Dimension in mm/inches
www.rohm.com
© 2012 ROHM Co., Ltd. All rights reserved.
e1
5/6
2012.07 - Rev.B
