BTA216X-600F

Description
Triacs RAIL TRIAC
CategoryAnalog mixed-signal IC    Trigger device
File Size202KB,14 Pages
ManufacturerNXP
Websitehttps://www.nxp.com
Environmental Compliance
Download Datasheet Parametric View All

BTA216X-600F Online Shopping

Suppliers Part Number Price MOQ In stock
BTA216X-600F - - View Buy Now

BTA216X-600F Overview

Triacs RAIL TRIAC

BTA216X-600F Parametric

Parameter NameAttribute value
Source Url Status Check Date2013-06-14 00:00:00
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerNXP
package instructionFLANGE MOUNT, R-PSFM-T3
Contacts3
Reach Compliance Codenot_compliant
Shell connectionISOLATED
ConfigurationSINGLE
Critical rise rate of minimum off-state voltage70 V/us
Maximum DC gate trigger current25 mA
Maximum DC gate trigger voltage1.5 V
Maximum holding current30 mA
JESD-30 codeR-PSFM-T3
JESD-609 codee3
Maximum leakage current0.5 mA
Number of components1
Number of terminals3
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum rms on-state current16 A
Off-state repetitive peak voltage600 V
surface mountNO
Terminal surfaceTin (Sn)
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
Trigger device typeTRIAC
Base Number Matches1
TO
-22
0A
B
BTA208-800E
3Q Hi-Com Triac
Rev. 05 — 12 April 2011
Product data sheet
1. Product profile
1.1 General description
Planar passivated high commutation three quadrant triac in a SOT78 plastic package.
This "series E" triac balances the requirements of commutation performance and gate
sensitivity. The "sensitive gate" "series E" is intended for interfacing with low power drivers
including microcontrollers.
1.2 Features and benefits
3Q technology for improved noise
immunity
Direct interfacing with low power
drivers and microcontrollers
Good immunity to false turn-on by
dV/dt
High commutation capability with
maximum false trigger immunity
High voltage capability
Planar passivated for voltage
ruggedness and reliability
Triggering in three quadrants only
1.3 Applications
Electronic thermostats
General purpose motor controls
1.4 Quick reference data
Table 1.
Symbol
V
DRM
I
TSM
Quick reference data
Parameter
repetitive peak
off-state voltage
non-repetitive peak
on-state current
RMS on-state current
full sine wave; T
j(init)
= 25 °C;
t
p
= 20 ms; see
Figure 4;
see
Figure 5
full sine wave; T
mb
102 °C;
see
Figure 1;
see
Figure 2;
see
Figure 3
V
D
= 12 V; I
T
= 0.1 A; T2+ G+;
T
j
= 25 °C; see
Figure 7
V
D
= 12 V; I
T
= 0.1 A; T2+ G-;
T
j
= 25 °C; see
Figure 7
V
D
= 12 V; I
T
= 0.1 A; T2- G-;
T
j
= 25 °C; see
Figure 7
Conditions
Min
-
-
Typ
-
-
Max Unit
800
65
V
A
I
T(RMS)
-
-
8
A
Static characteristics
I
GT
gate trigger current
-
-
-
-
-
-
10
10
10
mA
mA
mA
