NC7SZ05 — TinyLogic
®
UHS Inverter, Open Drain Output
September 2009
NC7SZ05
TinyLogic
®
UHS Inverter, Open Drain Output
Features
Ultra-High Speed: t
PD
1.9ns (Typical) into 50pF at
5V V
CC
Open Drain Output for OR Tied Applications
High Output Drive: +24mA at 3V V
CC
Broad V
CC
Operating Range: 1.65V to 5.5V
Matches Performance of LCX Operated at 3.3V V
CC
Power Down High-Impedance Inputs/Outputs
Over-Voltage Tolerance Inputs Facilitate 5V to 3V
Translation
Proprietary Noise/EMI Reduction Circuitry
Implemented
Ultra-Small MicroPak™ Packages
Space-Saving SOT23 and SC70 Packages
Description
The NC7SZ05 is a single inverter with open drain output
stage from Fairchild’s Ultra-High Speed series of
®
TinyLogic . The device is fabricated with advanced
CMOS technology to achieve ultra-high speed with high
output drive while maintaining low static power
dissipation over a broad V
CC
operating range. The
device is specified to operate over the 1.65V to 5.5V
V
CC
operating range. The inputs and output are high-
impedance when V
CC
is 0V. Inputs tolerate voltages up
to 6V, independent of V
CC
operating voltage. The open
drain output stage tolerates voltages up to 6V,
independent of V
CC
when in the high-impedance state.
Ordering Information
Part Number
NC7SZ05M5X
NC7SZ05P5X
NC7SZ05L6X
NC7SZ05FHX
Top Mark
7Z05
Z05
C6
C6
Eco Status
RoHS
RoHS
RoHS
Green
Package
5-Lead SOT23, JEDEC MO-178 1.6mm
5-Lead SC70, EIAJ SC-88a, 1.25mm Wide
6-Lead MicroPak™, 1.00mm Wide
6-Lead, MicroPak2, 1x1mm Body, .35mm
Pitch
Packing Method
3000 Units on
Tape & Reel
3000 Units on
Tape & Reel
5000 Units on
Tape & Reel
5000 Units on
Tape & Reel
