BZX84C4V3-7 Overview

Zener Diodes 4.3V 350mW

BZX84C4V3-7 Parametric

Parameter Name	Attribute value
Product Category	Zener Diodes
Manufacturer	Diodes
RoHS	No
Vz - Zener Voltage	4.3 V
Mounting Style	SMD/SMT
Package / Case	SOT-23
Pd - Power Dissipation	350 mW
Voltage Tolerance	5 %
Voltage Temperature Coefficient	- 1.75 mV/C
Zener Current	5 mA
Zz - Zener Impedance	90 Ohms
Minimum Operating Temperature	- 65 C
Maximum Operating Temperature	+ 150 C
Configuration	Single
Test Current	5 mA
Height	1 mm
Ir - Reverse Current	3 uA
Length	3.05 mm
Factory Pack Quantity	3000
Termination Style	SMD/SMT
Width	1.4 mm
Unit Weight	0.000282 oz

Preview

Download Datasheet

View All

BZX84C2V4 - BZX84C51

350mW SURFACE MOUNT ZENER DIODE

Features

•

Planar Die Construction

350mW Power Dissipation

Zener Voltages from 2.4V - 51V

Ideally Suited for Automated Assembly Processes

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

Mechanical Data

•

Case: SOT23

Case Material: Molded Plastic. UL Flammability Classification

Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Matte Tin Finish annealed over Alloy 42 leadframe

(Lead Free Plating). Solderable per MIL-STD-202, Method 208

Polarity: See Diagram

Weight: 0.008 grams (approximate)

SOT23

Top View

Device Schematic

Ordering Information

(Note 5)

Part Number

(Type Number)-7-F

(Type Number)Q-7-F

(Type Number)-13-F

(Type Number)Q-13-F

Notes:

Compliance

Standard

Automotive

Standard

Automotive

Case

SOT23

Packaging

3,000/Tape & Reel

10,000/Tape & Reel

*For (Type Number), please see the Electrical Characteristics Table. Example: 6.2V Zener = BZX84C6V2-7-F.

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. BZX84C2V4-BZX84C39 products manufactured with Date Code OW (week 42, 2009) and newer are built with Green Molding Compound. BZX84C2V4-

BZX84C39 products manufactured prior to Date Code OW are built with Non-Green Molding Compound and may contain Halogens or Sb

Fire

Retardants. BZX84C43-BZX84C51 products manufactured with Date Code V9 (week 33, 2008) and newer are built with Green Molding Compound.

BZX84C43-BZX84C51 products manufactured prior to Date Code V9 are built with Non-Green Molding Compound and may contain Halogens or Sb

Fire Retardants.

5. For packaging details, go to our website at http://www.diodes.com/products/packages.html

Marking Information

Kxx

Date Code Key

Year

1998

Code

Month

Code

Jan

…

2002

Feb

2003

Mar

2004

2005

Apr

2006 2007

May

2008

Jun

2009

Jul

2010

2011

Aug

Kxx

xx = Product Type Marking Code

(See Electrical Characteristics Table)

YM = Date Code Marking for Shanghai

Assembly / Test site

Y = Year (ex: Z = 2012)

M = Month (ex: 9 = September)

xx = Product Type Marking Code

(See Electrical Characteristics Table)

= Date Code Marking for Chengdu

Assembly / Test site

= Year (ex: Z = 2012)

M = Month (ex: 9 = September)

2012

Sep

2013

2014

Oct

2015

Nov

2016

2017

Dec

BZX84C2V4 - BZX84C51

Document number: DS18001 Rev. 32 - 2

1 of 5

www.diodes.com

February 2014

BZX84C2V4 - BZX84C51

IMPORTANT NOTICE

DIODES INCORPORATED MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARDS TO THIS DOCUMENT,

INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE

(AND THEIR EQUIVALENTS UNDER THE LAWS OF ANY JURISDICTION).

Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes

without further notice to this document and any product described herein. Diodes Incorporated does not assume any liability arising out of the

application or use of this document or any product described herein; neither does Diodes Incorporated convey any license under its patent or

trademark rights, nor the rights of others. Any Customer or user of this document or products described herein in such applications shall assume

all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on Diodes Incorporated

website, harmless against all damages.

Diodes Incorporated does not warrant or accept any liability whatsoever in respect of any products purchased through unauthorized sales channel.

Should Customers purchase or use Diodes Incorporated products for any unintended or unauthorized application, Customers shall indemnify and

hold Diodes Incorporated and its representatives harmless against all claims, damages, expenses, and attorney fees arising out of, directly or

indirectly, any claim of personal injury or death associated with such unintended or unauthorized application.

Products described herein may be covered by one or more United States, international or foreign patents pending. Product names and markings

noted herein may also be covered by one or more United States, international or foreign trademarks.

This document is written in English but may be translated into multiple languages for reference. Only the English version of this document is the

final and determinative format released by Diodes Incorporated.

LIFE SUPPORT

Diodes Incorporated products are specifically not authorized for use as critical components in life support devices or systems without the express

written approval of the Chief Executive Officer of Diodes Incorporated. As used herein:

A. Life support devices or systems are devices or systems which:

1. are intended to implant into the body, or

2. support or sustain life and whose failure to perform when properly used in accordance with instructions for use provided in the

labeling can be reasonably expected to result in significant injury to the user.

B. A critical component is any component in a life support device or system whose failure to perform can be reasonably expected to cause the

failure of the life support device or to affect its safety or effectiveness.

Customers represent that they have all necessary expertise in the safety and regulatory ramifications of their life support devices or systems, and

acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products and any

use of Diodes Incorporated products in such safety-critical, life support devices or systems, notwithstanding any devices- or systems-related

information or support that may be provided by Diodes Incorporated. Further, Customers must fully indemnify Diodes Incorporated and its

representatives against any damages arising out of the use of Diodes Incorporated products in such safety-critical, life support devices or systems.

www.diodes.com

BZX84C2V4 - BZX84C51

Document number: DS18001 Rev. 32 - 2

5 of 5

www.diodes.com

February 2014
