Product Profile
00422
The Leading Edge in EMI Shielding Technology
Applications
-
-
-
-
Short lead times
Automatic placement
Cost effective
No tooling costs
One-Piece SMS Surface Mount Shield
Leader Tech SMS - Surface Mount Shields offer a highly reliable, cost effective, off-the-shelf solution
for most surface mount shielding applications. Our SMS shields are supplied in tape & reel packaging
and are suited for any volume application including automated pick and place assembly operations.
Our one piece SMS style can be specified for applications that require no inspection or repair of
shielded elements.
Material
Pre-tin plated steel
Alloy 770
One-Piece
SMS Shields
One-Piece
- Form down construction
supplied in tape & reel
packaging
Note: Click on part number to see Technical Drawing
ONE-PIECE SURFACE MOUNT SHIELD
Shield Width
0.500
0.500
0.650
0.650
1.000
1.000
1.032
1.032
1.260
1.260
1.326
1.326
1.747
1.747
12.700
12.700
16.510
16.510
25.400
25.400
26.213
26.213
32.004
32.004
33.680
33.680
44.374
44.374
Shield Length
0.538
0.538
0.650
0.650
1.500
1.500
1.032
1.032
1.260
1.260
1.450
1.450
1.747
1.747
13.665
13.665
16.510
16.510
38.100
38.100
26.213
26.213
32.004
32.004
36.830
36.830
44.374
44.374
Shield Height
0.100
0.100
0.142
0.142
0.236
0.236
0.200
0.200
0.236
0.236
0.200
0.200
0.384
0.384
2.540
2.540
3.607
3.607
5.994
5.994
5.080
5.080
5.994
5.994
5.080
5.080
9.754
9.754
Vented
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Parts per
Reel
1000
1000
700
700
250
250
300
300
225
225
300
300
120
120
Material Options
Standard
.008” Pre-Tin Matte Steel
.008” Pre-Tin Matte Steel
.008” Pre-Tin Matte Steel
.008” Pre-Tin Matte Steel
.008” Pre-Tin Matte Steel
.008” Pre-Tin Matte Steel
.008” Pre-Tin Matte Steel
.008”
.008”
.008”
.008”
.008”
.008”
Pre-Tin
Pre-Tin
Pre-Tin
Pre-Tin
Pre-Tin
Pre-Tin
Matte
Matte
Matte
Matte
Matte
Matte
Steel
Steel
Steel
Steel
Steel
Steel
**add -N to P/N
008” Alloy 770**
008” Alloy 770**
008” Alloy 770**
008” Alloy 770**
008” Alloy 770**
008” Alloy 770**
008” Alloy 770**
008”
008”
008”
008”
008”
008”
Alloy
Alloy
Alloy
Alloy
Alloy
Alloy
770**
770**
770**
770**
770**
770**
Part
Number
SMS-101
SMS-301
SMS-102
SMS-302
SMS-105
SMS-305
SMS-103
SMS-303
SMS-104
SMS-304
SMS-106
SMS-306
SMS-107
SMS-307
Shield shown in tape & reel packaging
.008” Pre-Tin Matte Steel
008” Alloy 770**
Black = inches
Blue = mm
**When ordering Alloy 770 include ‘-N’ in part number. Example: SMS-1XX-N
Surface Mount Shield
Global EMI Shielding Technology Center
12420 Race Track Rd., Tampa, Florida 33626
866.TECH.EMI (866.832.4364) t 813.855.6921 f 813.855.3291
STATEMENT OF LIEU OF WARRANTY: All technical information and data in this document is based on tests and is believed to be accurate and reliable. Nevertheless, since
the products described herein are not provided to conform with mutually accepted specifications and the use thereof is unknown, the manufacturer and seller of the products
do not guarantee results, freedom from patent infringement, or suitability of the products for any application thereof. The manufacturer and seller of the products described
in this document will provide all possible technical assistance and will replace any products proven defective. No statement or recommendations made by the manufacturer
or seller not contained herein shall have any force of effect unless in conformity with an agreement signed by an officer of the seller and manufacturer. Product testing by the
purchaser is recommended in order to confirm expected results.
