High Current, MIL-PRF-27/370 Qualified
Surface Mount Power Inductors
SH
DA
Actual Size
Mechanical Configuration
Units are encapsulated in a Surface Mount package,using
an epoxy molded case. High resistivity ferrite core, allows
for high inductance with low DC resistance.
Physical Parameters
Inches
Millimeters
A
0.840 to 0.880
21.34 to 22.35
B
0.310 to 0.330
7.87 to 8.38
C
0.266 to 0.286
6.76 to 7.26
D
0.050 Min.
1.27 Min.
E
0.070 to 0.110
1.78 to 2.79
F
0.750 (Ref. only)
19.05 (Ref. only)
G
0.120 (Ref. only)
3.05 (Ref. only)
Dimensions “A” and “C” are over terminals.
Operating Temperature Range
–55°C to +130°C
Current Rating at 85°C Ambient
45°C Rise
Maximum Power Dissipation at 85°C
0.50 W
Inductance
Measured at 1 VAC open circuit with no DC current
Incremental Current
The current at which the
inductance will decrease by a maximum of 5% from
its inductance at zero DC current.
Weight
(Grams Max.) 2.5
Packaging
Tape & reel (44mm):
13" reel, 480 pieces max.; 7" reel not available
Lead Finish
Sn63Pb37
(Tin-Lead) Hot Solder Dipped
Made In the U.S.A.
M27/370 - SERIES MIL8532 FERRITE
-01
1.0
0.009
-02
1.2
0.010
-03
1.5
0.011
-04
1.8
0.012
-05
2.2
0.013
-06
2.7
0.014
-07
3.3
0.016
-08
3.9
0.017
-09
4.7
0.022
-10
5.6
0.024
-11
6.8
0.026
-12
8.2
0.028
-13
10.0
0.033
-14
12.0
0.037
-15
15.0
0.040
-16
18.0
0.044
-17
22.0
0.050
-18
27.0
0.070
-19
33.0
0.075
-20
39.0
0.084
-21
47.0
0.104
-22
56.0
0.130
-23
68.0
0.145
-24
82.0
0.152
-25
100.0
0.208
-26
120.0
0.283
-27
150.0
0.330
-28
180.0
0.362
-29
220.0
0.505
-30
270.0
0.557
-31
330.0
0.650
-32
390.0
0.770
-33
470.0
1.03
-34
560.0
1.14
-35
680.0
1.50
-36
820.0
1.98
-37
1000.0
2.30
-38
1200.0
2.55
-39
1500.0
3.00
-40
1800.0
4.00
-41
2200.0
4.40
-42
2700.0
5.80
-43
3300.0
6.56
-44
3900.0
8.63
-45
4700.0
10.1
-46
5600.0
11.2
-47
6800.0
15.0
-48
8200.0
20.8
-49
10000.0
23.4
-50
12000.0
26.0
-51
15000.0
36.0
-52
18000.0
40.0
CORE
6.27
5.95
5.67
5.43
5.22
5.03
4.70
4.56
4.01
3.84
3.69
3.55
3.27
3.09
2.97
2.84
2.66
2.25
2.17
2.05
1.84
1.65
1.56
1.53
1.30
1.12
1.04
0.99
0.84
0.80
0.74
0.68
0.59
0.56
0.49
0.42
0.39
0.37
0.34
0.30
0.28
0.25
0.23
0.20
0.19
0.18
0.15
0.13
0.12
0.12
0.10
0.09
6.4
5.8
5.2
4.8
4.3
3.9
3.5
3.2
2.9
2.7
2.5
2.2
2.0
1.8
1.6
1.5
1.4
1.2
1.1
1.0
0.93
0.85
0.77
0.71
0.64
0.58
0.52
0.48
0.43
0.39
0.35
0.32
0.29
0.27
0.25
0.22
0.20
0.18
0.16
0.15
0.14
0.12
0.11
0.10
0.09
0.09
0.08
0.07
0.06
0.06
0.05
0.05
*Complete part # must include series # PLUS the dash #
