NOTES:
1. ROTOR AND STATOR TO BE AXIALLY ALIGNED WITH
-C-
WITHIN .015.
2. MAX. ERROR FROM E-Z OF ±13 MINUTES WHEN ROTOR IS MOUNTED ON SHAFT WHERE
RUNOUT IS .003 F.I.R. AND MOUNTING CONCENTRICITY OF STATOR IS .004 F.I.R.
TYPICAL MECHANICAL DATA
TEMPATURE RANGE
ºC -55 to +155
ROTOR MOMENT OF INERTIA OZ-IN-SEC²
.09
WEIGHT
OZ. AVG.
21
B
B
C
1.250
1.245
.584
.579
DELTRAN PT - HAROWE
31BRCX-500-B7/10
S/N:
ST. KITTS, WEST INDIES
D/C:
.187
.125
1007116-568
NAMEPLATE
TYPICAL ELECTRICAL DATA
INPUT VOLTAGE
VOLTS RMS
INPUT CURRENT
MAX. MA
INPUT POWER
NOM. WATTS
IMPEDANCE ZRO
OHMS
IMPEDANCE ZRS
OHMS
IMPEDANCE ZSO
OHMS
IMPEDANCE ZSS
OHMS
TRANSFORMATION RATIO
±10%
OUTPUT VOLTAGE
±10% VOLTS
DC ROTOR RESISTANCE
±15% OHMS
DC STATOR RESISTANCE
±15% OHMS
MAX ERROR
MINUTES
PHASE SHIFT (OPEN CIRCUIT)
NOM.
NULL VOLTAGE TOTAL RMS
MV
HIPOT TO CASE
60HZ
VRMS
HIPOT BETWEEN PHASES 60HZ
VRMS
5000 HZ
4.0
30
.05
75+J120
70+J105
225+J385
200+J355
.500
2.0
35
93
±10
+1
20
500
250
3.050
3.048
.002
2X .025 X 45º
CHAMFER
1.5617
1.5607
2.950
.001
3.050
.056/.060 WIDE X
1.622/1.612
GROOVE PER SS-161.
R1
RED/WHT
RED
S1
R2
YELLOW
SCHEMATIC
#24 AWG (ET) LEADS
12" MIN. LENGTH
S2
S4
PHASING EQUATION
FOR CCW ROTATION OF ROTOR FACING
TRANSFORMER MOUNTING FLANGE END.
E(S1-S3)= KE(R1-R2) COS Ø
E(S2-S4)= KE(R1-R2) SIN Ø
THIS DRAWING HAS BEEN
CREATED BY CAD/CAM. DO NOT
MANUALLY REVISE OR UPDATE.
TOLERANCES
UNLESS SPECIFIED
DECIMAL
.XXX
±.005
DECIMAL
.XX
±.010
DECIMAL
.X
±.030
FRACTION
ANGLES
DRAWN
CHECKED
ENGR
±1/64
±0°30'
DELTRAN PT - Harowe
PROPRIETARY RIGHTS OF DELTRAN PT - HAROWE ARE INCLUDED IN THE
INFORMATION DISCLOSED HEREIN. DO NOT DUPLICATE OR DISCLOSE TO
THIRD PARTIES WITHOUT WRITTEN PERMISSION OF DELTRAN PT.
D. HERRINGTON
Tolerancing Complies With ANSI/ASME Y14.5M-1994
CHG.
REVISIONS
DATE
APPR.
CHG.
REVISIONS
DATE
APPR.
CHG.
REVISIONS
DATE
APPR.
B
A
CHG.
RKT 10/11/01
RESOLVER BRUSHLESS FRAMELESS
10/01 RKT
APPROV
ECO#D5740
ECO#16792
REVISIONS
OUTLINE & PERFORMANCE
SPECIFICATIONS
DWG.
NO.
5/01
DATE
APPR.
CODE IDENT NO.
SCALE
58655
2:1
31BRCX-500-B7/10
BLUE
YEL/WHT
ROTOR
PRIMARY
BLACK
S3
STATOR
SECONDARY
SHEET 1 OF 2
B
