Operating Temperature Range ...........................-40°C to +85°C
Storage Temperature Range .............................-65°C to +165°C
Junction Temperature ......................................................+150°C
Lead Temperature (soldering, 10s) .................................+300°C
Note 1:
Backside slug must be properly soldered to ground plane (see
Slug Layout Techniques
section).
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
DC ELECTRICAL CHARACTERISTICS
(T
A
= T
MIN
to T
MAX
, unless otherwise noted.)
PARAMETER
Collector-Emitter Breakdown
Voltage
Collector-Emitter Sustaining
Voltage
Collector-Base Breakdown
Voltage
DC Current Gain
Collector Cutoff Current
Output Capacitance
SYMBOL
BV
CEO
BV
CES
LV
CEO
BV
CBO
h
FE
I
CES
C
OB
I
C
< 100µA
I
C
= 200mA
I
C
< 100µA, emitter open
I
C
= 250mA, V
CE
= 3V
V
CE
= 6V, V
BE
= 0V
V
CB
= 3V, I
E
= 0mA, f = 1MHz
CONDITIONS
Open base
Shorted base
MIN
15
15
5.0
15
100
0.05
9.6
1.5
µA
pF
TYP
MAX
UNITS
V
V
V
AC ELECTRICAL CHARACTERISTICS
(Test Circuit of Figure 1, V
CC
= 3.6V, V
BB
= 0.750V, Z
LOAD
= Z
SOURCE
= 50Ω, P
OUT
= 30dBm, f = 836MHz, T
A
= +25°C, unless oth-
erwise noted.)
PARAMETER
Frequency Range
Base Current
Harmonics
Power Gain
Collector Efficiency
Stability under Continuous
Load Mismatch Conditions
Two-Tone IMR
Noise Figure
η
V
SWR
IM3
IM5
NF
SYMBOL
f
I
B
2fo, 3fo
V
CC
= 3.6V, P
OUT
= 30dBm
V
CC
= 3.0V, P
OUT
= 29dBm
P
OUT
= 30dBm
No modulation
V
CC
= 5.5V, all angles (Note 3)
P
OUT
= +30dBm total power, f1 = 835MHz,
f2 = 836MHz
V
BB
= 0.9V
(Note 2)
CONDITIONS
MIN
DC
4.2
-43
-42
11.6
58
8:1
-16
-25
3.3
dBc
dB
TYP
MAX
1
UNITS
GHz
mA
dBc
dBc
dB
%
Note 2:
Guaranteed by design.
Note 3:
Under these conditions: a) no spurious oscillations shall be observed at collector greater than -60dBc; b) no parametric
degradation is observable when mismatch is removed; and c) no current draw in excess of the package dissipation
