Da ta She et, V2. 2, Aug . 2 00 1
C167CS-4R
C167CS-L
16-Bit Single-Chip Microcontroller
Microcontrollers
N e v e r
s t o p
t h i n k i n g .
Edition 2001-08
Published by Infineon Technologies AG,
St.-Martin-Strasse 53,
D-81541 München, Germany
©
Infineon Technologies AG 2001.
All Rights Reserved.
Attention please!
The information herein is given to describe certain components and shall not be considered as warranted
characteristics.
Terms of delivery and rights to technical change reserved.
We hereby disclaim any and all warranties, including but not limited to warranties of non-infringement, regarding
circuits, descriptions and charts stated herein.
Infineon Technologies is an approved CECC manufacturer.
Information
For further information on technology, delivery terms and conditions and prices please contact your nearest
Infineon Technologies Office in Germany or our Infineon Technologies Representatives worldwide.
Warnings
Due to technical requirements components may contain dangerous substances. For information on the types in
question please contact your nearest Infineon Technologies Office.
Infineon Technologies Components may only be used in life-support devices or systems with the express written
approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the failure
of that life-support device or system, or to affect the safety or effectiveness of that device or system. Life support
devices or systems are intended to be implanted in the human body, or to support and/or maintain and sustain
and/or protect human life. If they fail, it is reasonable to assume that the health of the user or other persons may
be endangered.
Da ta She et, V2. 2, Aug . 2 00 1
C167CS-4R
C167CS-L
16-Bit Single-Chip Microcontroller
Microcontrollers
N e v e r
s t o p
t h i n k i n g .
C167CS
Revision History:
Previous Version:
2001-08
2000-12
2000-06
1999-06
1999-03
V2.1 (Intermediate version)
V2.0
(Advance Information)
V2.2
Page
4
25, 27
50ff
52f
54
57
59
60
76
Page
All
2
52
53
56
60f
64
65
70
71
72
75
1)
Subjects (major changes from V2.1, 2000-12 to V2.2, 2001-08)
Figure 2
corrected (pins 98, 99)
Figure 5
and
Figure 6
updated
Output voltage/current specification improved
Limit values for
I
IDO
and
I
PDR
increased due to the usage of a standard
oscillator
Figure 10
corrected
Figure 12
updated for 40 MHz
Clock parameters adjusted
TUE note includes P1H
Package drawing updated
1)
Subjects (major changes from V2.0, 2000-06 to V2.1, 2000-12)
Maximum operating frequency updated to 40 MHz
Derivative table updated
RSTIN level for
I
DD
corrected to
V
IL
(was
V
IL2
)
Current unit corrected to
µ
A
Input clock range adjusted
Note 5 detailed
Parameters
tc
10
,
tc
12
,
tc
13
,
tc
14
,
tc
15
,
tc
16
,
tc
17
,
tc
18
,
tc
19
changed
Relative bus timing parameters added
Parameter
tc
25
changed, notes adapted
Notes adapted
Parameter
tc
28
changed
Parameters
t
42
,
t
43
,
t
44
,
t
46
,
t
47
changed
New package due to new assembly line. MQFP-144-1 for current deliveries only, will be discontinued.
Controller Area Network (CAN): License of Robert Bosch GmbH
We Listen to Your Comments
Any information within this document that you feel is wrong, unclear or missing at all?
Your feedback will help us to continuously improve the quality of this document.
Please send your proposal (including a reference to this document) to:
mcdocu.comments@infineon.com
16-Bit Single-Chip Microcontroller
C166 Family
C167CS-4R, C167CS-L
C167CS
• High Performance 16-bit CPU with 4-Stage Pipeline
– 80/60/50 ns Instruction Cycle Time at 25/33/40 MHz CPU Clock
– 400/303/250 ns Multiplication (16
×
16 bit), 800/606/500 ns Division (32-/16-bit)
– Enhanced Boolean Bit Manipulation Facilities
– Additional Instructions to Support HLL and Operating Systems
– Register-Based Design with Multiple Variable Register Banks
– Single-Cycle Context Switching Support
– 16 MBytes Total Linear Address Space for Code and Data
– 1024 Bytes On-Chip Special Function Register Area
• 16-Priority-Level Interrupt System with 56 Sources, Sample-Rate down to 40/30/25 ns
• 8-Channel Interrupt-Driven Single-Cycle Data Transfer Facilities via
Peripheral Event Controller (PEC)
• Clock Generation via on-chip PLL (factors 1:1.5/2/2.5/3/4/5),
via prescaler or via direct clock input
• On-Chip Memory Modules
– 3 KBytes On-Chip Internal RAM (IRAM)
– 8 KBytes On-Chip Extension RAM (XRAM)
– 32 KBytes On-Chip Program Mask ROM
• On-Chip Peripheral Modules
– 24-Channel 10-bit A/D Converter with Programmable Conversion Time
down to 7.8
µ
s
– Two 16-Channel Capture/Compare Units
– 4-Channel PWM Unit
– Two Multi-Functional General Purpose Timer Units with 5 Timers
– Two Serial Channels (Synchronous/Asynchronous and High-Speed-Synchronous)
– Two On-Chip CAN Interfaces (Rev. 2.0B active) with 2
×
15 Message Objects
(Full CAN/Basic CAN), can work on one bus with 30 objects
– On-Chip Real Time Clock
• Up to 16 MBytes External Address Space for Code and Data
– Programmable External Bus Characteristics for Different Address Ranges
– Multiplexed or Demultiplexed External Address/Data Buses with 8-Bit or 16-Bit
Data Bus Width
– Five Programmable Chip-Select Signals
– Hold- and Hold-Acknowledge Bus Arbitration Support
• Idle, Sleep, and Power Down Modes with Flexible Power Management
• Programmable Watchdog Timer and Oscillator Watchdog
• Up to 111 General Purpose I/O Lines,
partly with Selectable Input Thresholds and Hysteresis
Data Sheet
1
V2.2, 2001-08
