LVDS Interface ICs
4bit LVDS Receiver
BU90LV048
●Description
LVDS Interface IC of ROHM "Serializer" "Deserializer" operate from 8MHz to 150MHz wide clock range, and number of bits
range is from 35 to 70. Data is transmitted seven times (7X) stream and reduce cable number by 3(1/3) or less. The
ROHM's LVDS has low swing mode to be able to expect further low EMI.
Driver and Receiver of 4 bits operate to 250MHz. It can be used for a variety of purposes, home appliances such as
LCD-TV, business machines such as decoders, instruments, and medical equipment.
No.12057EAT03
●Features
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
>500 Mbps (250 MHz) switching rates
Flow-through pinout simplifies PCB layout
150 ps channel-to-channel skew (typical)
100 ps differential skew (typical)
3.7 ns maximum propagation delay
3.3V power supply design
6mA and 8mA selectable output drive strength
Accepts small swing (200 mV typical) differential signal levels
Supports open, short and terminated input fail-safe
Conforms to ANSI/TIA/EIA-644 Standard
Industrial temperature operating range (-40℃ to +85℃)
●Applications
Car Navigation System
Copier
Digital TV (Signal System)
FA equipment
Medical equipment
Vending machine, Ticket vending machine
●Precaution
■This
chip is not designed to protect from radioactivity.
■This
document may be used as strategic technical data
which subjects to COCOM regulations.
www.rohm.com
© 2011 ROHM Co., Ltd. All rights reserved.
1/11
2011.12 - Rev.A
BU90LV048
●Pin
Description
Table 1 : Pin Description
Pin Name
R
IN+
R
IN-
R
OUT
Pin No.
2, 3, 6, 7
1, 4, 5, 8
10, 11, 14, 15
Type
LVDS In
LVDS In
LVCMOS Out
LVCMOS In
SL
9
LVCMOS In
EN
V
CC
GND
16
13
12
Power
GND
Descriptions
Non-inverting receiver input pin
Inverting receiver input pin
Receiver output pin
Technical Note
Drive strength select pin :
When SL is low or open, Rout set 8mA
mode.
When SL is high, Rout set 6mA mode.
Receiver enable pin: When EN is
Low or open, the receiver is disabled. When
EN is high, the receiver is enabled.
Power supply pin, +3.3V±0.3V
Ground pin
●Function
Description
INPUT
EN
SL
R
IN+
−
R
IN−
VID
H
L or Open
VID
0V
−
0.1V
OUTPUTS
Drive Strength
R
OUT
H
L
H
H
L
H
Z
6mA
8mA
Full Fail-safe
OPEN/SHORT
or Terminated
VID
H
H
VID
0V
−
0.1V
Full Fail-safe
OPEN/SHORT
or Terminated
All other combinations of EN, SL inputs
X
www.rohm.com
© 2011 ROHM Co., Ltd. All rights reserved.
5/11
2011.12 - Rev.A
