GBPC6005, GBPC601, GBPC602, GBPC604, GBPC606, GBPC608, GBPC610
www.vishay.com
Vishay General Semiconductor
Glass Passivated Single-Phase Bridge Rectifier
FEATURES
~
~
~
~
Case Style GBPC6
• UL recognition file number E54214
• Ideal for printed circuit boards
• Typical I
R
less than 0.5 μA
• High surge current capability
• High case dielectric strength 1500 V
RMS
• Solder dip 275 °C max. 10 s, per JESD 22-B106
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
e4
PRIMARY CHARACTERISTICS
Package
I
F(AV)
V
RRM
I
FSM
I
R
V
F
at I
F
= 3.0 A
T
J
max.
Diode variations
GBPC6
6A
50 V, 100 V, 200 V, 400 V, 600 V,
800 V, 1000 V
175 A
5 μA
1.0 V
150 °C
Quad
TYPICAL APPLICATIONS
General purpose use in AC/DC bridge full wave rectification
for power supply, home appliances, office equipment,
industrial automation applications.
MECHANICAL DATA
Case:
GBPC6
Molding compound meets UL 94 V-0 flammability rating
Base P/N-E4 - RoHS-compliant, commercial grade
Terminals:
Silver plated
J-STD-002 and JESD22-B102
leads,
solderable
per
Polarity:
As marked, positive lead by beveled corner
Mounting Torque:
10 cm-kg (8.8 in-lbs) maximum
Recommended Torque:
5.7 cm-kg (5 in-lbs) maximum
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS bridge input voltage
Maximum DC blocking voltage
Maximum average forward
rectified output current at
T
C
= 50 °C
(1)(2)
T
A
= 40 °C
(3)
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
I
2
t
T
J
, T
STG
GBPC
6005
50
35
50
GBPC
601
100
70
100
GBPC
602
200
140
200
GBPC
604
400
280
400
6.0
3.0
175
127
- 55 to + 150
GBPC
606
600
420
600
GBPC
608
800
560
800
GBPC
610
1000
700
1000
UNIT
V
V
V
A
A
A
2
s
°C
Peak forward surge current single sine-wave
superimposed on rated load
Rating for fusing (t = 8.3 ms)
Operating junction and storage temperature range
Notes
(1)
Bolt down on heat-sink with silicone thermal compound between bridge and mounting surface for maximum heat transfer with #6 screw
(2)
Unit mounted on 5.5" x 6.0" x 0.11" thick (14 cm x 15 cm x 0.3 cm) aluminum plate
(3)
Unit mounted on PCB at 0.375" (9.5 mm) lead length with 0.5" x 0.5" (12 mm x 12 mm) copper pads
Revision: 08-Jul-13
Document Number: 88613
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
GBPC6005, GBPC601, GBPC602, GBPC604, GBPC606, GBPC608, GBPC610
www.vishay.com
Vishay General Semiconductor
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum instantaneous forward
voltage drop per diode
Maximum DC reverse current at
rated DC blocking voltage per
diode
Typical junction capacitance per
diode
SYMBOL
V
F
I
R
C
J
TEST
CONDITIONS
3.0 A
T
A
= 25 °C
T
A
= 125 °C
4.0 V, 1 MHz
186
GBPC
6005
GBPC
601
GBPC
602
GBPC
604
1.0
5.0
500
90
μA
pF
GBPC
606
GBPC
608
GBPC
610
UNIT
V
THERMAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Typical thermal resistance
(1)
SYMBOL
R
JA
R
JC
GBPC
6005
GBPC
601
GBPC
602
GBPC
604
22
7.3
GBPC
606
GBPC
608
GBPC
610
UNIT
°C/W
Notes
(1)
Bolt down on heat-sink with silicone thermal compound between bridge and mounting surface for maximum heat transfer with #6 screw
(2)
Unit mounted on 5.5" x 6.0" x 0.11" thick (14 cm x 15 cm x 0.3 cm) aluminum plate
(3)
Unit mounted on PCB at 0.375" (9.5 mm) lead length with 0.5" x 0.5" (12 mm x 12 mm) copper pads
ORDERING INFORMATION
(Example)
PREFERRED P/N
GBPC606-E4/51
UNIT WEIGHT (g)
3.2
PACKAGE CODE
51
BASE QUANTITY
100
DELIVERY MODE
Paper box
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
8.0
200
Peak Forward Surge Current (A)
6.0
Case Temperature,
T
C
Heatsink Mounting
5.5 x 6.0 x 0.11" Thk.
(14 x 15 x 0.3 cm)
Al. Plate
60 Hz Resistive or
Inductive Load
T
J
= T
J
Max.
Single Sine-Wave
175
150
4.0
125
100
2.0
Ambient Temperature, T
A
P.C.B. Mounting
0.375" (9.5 mm) Lead Length
0
0
50
100
150
75
1.0 Cycle
50
1
10
100
Temperature (°C)
Number
of Cycles at 60 Hz
Fig. 1 -
Derating Curve Output Rectified Current
Fig. 2 -
Maximum Non-Repetitive Peak Forward Surge
Current Per Diode
Revision: 08-Jul-13
Document Number: 88613
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
GBPC6005, GBPC601, GBPC602, GBPC604, GBPC606, GBPC608, GBPC610
www.vishay.com
Vishay General Semiconductor
1000
T
J
= 25 °C
f = 1.0 MHz
V
sig
= 50 mVp-p
100
Instantaneous Forward Current (A)
10
1
Junction Capacitance (pF)
100
0.1
T
J
= 25 °C
Pulse Width = 300 µs
1 % Duty Cycle
0.01
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
50 - 400 V
600 - 1000 V
10
0.1
1
10
100
Instantaneous Forward Voltage (V)
Reverse Voltage (V)
Fig. 3 -
Typical Forward Characteristics Per Diode
Fig. 5 -
Typical Junction Capacitance Per Diode
1000
100
T
A
= 125 °C
100
T
J
= 100 °C
10
Transient Thermal Impedance (°C/W)
80
100
Instantaneous Reverse Current (µA)
10
1
1
T
J
= 25 °C
0.1
0
20
40
60
0.1
0.01
0.1
1
10
100
Percent of Rated Peak Reverse Voltage (%)
t - Heating Time (s)
Fig. 4 -
Typical Reverse Leakage Characteristics Per Diode
Fig. 6 -
Typical Transient Thermal Impedance Per Diode
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
Case Style GBPC6
Hole For #6 Screw
0.158 (4.01)
DIA.
0.142 (3.61)
0.630 (16.00)
0.590 (14.98)
0.445 (11.30)
0.405 (10.29)
AC
0.630 (16.00)
0.590 (14.98)
0.445 (11.30)
0.405 (10.29)
AC
0.128 (3.25)
0.048 (1.22)
0.042 (1.07)
DIA.
0.038 (0.96)
0.094 (2.4) x 45°
0.040 (1.02) TYP.
0.750 (19.05)
MIN.
0.200 (5.08)
0.160 (4.06)
Polarity shown on side of case: Positive lead
by beveled
corner
Revision: 08-Jul-13
Document Number: 88613
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
