BZT52C2V7-13-F

Description
Headers u0026 Wire Housings 4 CKT R/A HEADER
Categorysemiconductor    Discrete semiconductor
File Size388KB,5 Pages
ManufacturerDiodes
Websitehttp://www.diodes.com/
Download Datasheet Parametric Compare View All

BZT52C2V7-13-F Online Shopping

Suppliers Part Number Price MOQ In stock
BZT52C2V7-13-F - - View Buy Now

BZT52C2V7-13-F Overview

Headers u0026 Wire Housings 4 CKT R/A HEADER

BZT52C2V7-13-F Parametric

Parameter NameAttribute value
Product CategoryZener Diodes
ManufacturerDiodes
RoHSDetails
Vz - Zener Voltage2.7 V
Mounting StyleSMD/SMT
Package / CaseSOD-123-2
Pd - Power Dissipation500 mW (1/2 W)
Voltage Tolerance7.41 %
Voltage Temperature Coefficient- 3.5 mV/C
Zener Current20 uA
Zz - Zener Impedance100 Ohms
Minimum Operating Temperature- 65 C
Maximum Operating Temperature+ 150 C
ConfigurationSingle
PackagingCut Tape
PackagingMouseReel
PackagingReel
Height1.35 mm
Ir - Reverse Current20 uA
Length3.85 mm
ProductZener Diode
Factory Pack Quantity10000
Vf - Forward Voltage0.9 V
Width1.7 mm
BZT52C2V0 - BZT52C51
SURFACE MOUNT ZENER DIODE
Features
Planar Die Construction
500mW Power Dissipation
General Purpose, Medium Current
Ideally Suited for Automated Assembly Processes
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Notes 3 & 4)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
Case: SOD123
Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Matte Tin Finish Annealed over Alloy 42 Leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
Polarity: Cathode Band
Weight: 0.010 grams (Approximate)
SOD123
Top View
Ordering Information
(Notes 5 & 6)
Part Number
(Type Number)-7-F
(Type Number)Q-7-F
(Type Number)-13-F
(Type Number)Q-13-F
Notes:
Qualification
Commercial
Automotive
Commercial
Automotive
Case
SOD123
SOD123
SOD123
SOD123
Packaging
3,000/Tape & Reel
3,000/Tape & Reel
10,000/Tape & Reel
10,000/Tape & Reel
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. Product manufactured with Date Code V9 (week 33, 2008) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code V9 are built with Non-Green Molding Compound and may contain Halogens or Sb
2
O
3
Fire Retardants.
5. For packaging details, go to our website at http://www.diodes.com.
6. For (Type Number), please see the Electrical Characteristics Table. Example: 6.2V Zener = BZT52C6V2Q-13-F.
Marking Information
xx = Product Type Marking Code
(See Electrical Characteristics Table)
YM = Date Code Marking
Y = Year (ex: E = 2017)
M = Month (ex: 9 = September)
Date Code Key
Year
2013
Code
A
Month
Code
Jan
1
2014
B
Feb
2
2015
C
Mar
3
Apr
4
2016
D
May
5
2017
E
Jun
6
Jul
7
2020
H
Aug
8
2021
I
Sep
9
2022
J
Oct
O
2023
K
Nov
N
2024
L
Dec
D
BZT52C2V0 - BZT52C51
Document number: DS18004 Rev. 38 - 2
1 of 5
www.diodes.com
October 2017
© Diodes Incorporated
