Microchip received ISO/TS-16949:2002 certification for its worldwide
headquarters, design and wafer fabrication facilities in Chandler and
Tempe, Arizona; Gresham, Oregon and design centers in California
and India. The Company’s quality system processes and procedures
are for its PIC
®
MCUs and dsPIC
®
DSCs, K
EE
L
OQ
®
code hopping
devices, Serial EEPROMs, microperipherals, nonvolatile memory and
analog products. In addition, Microchip’s quality system for the design
and manufacture of development systems is ISO 9001:2000 certified.
DS39682E-page ii
©
2009 Microchip Technology Inc.
PIC18F45J10 FAMILY
28/40/44-Pin High-Performance, RISC Microcontrollers
Special Microcontroller Features:
•
•
•
•
•
•
•
Operating Voltage Range: 2.0V to 3.6V
5.5V Tolerant Input (digital pins only)
On-Chip 2.5V Regulator
4x Phase Lock Loop (PLL) available for Crystal
and Internal Oscillators
Self-Programmable under Software Control
Low-Power, High-Speed CMOS Flash Technology
C Compiler Optimized Architecture:
- Optional extended instruction set designed to
optimize re-entrant code
Priority Levels for Interrupts
8 x 8 Single-Cycle Hardware Multiplier
Extended Watchdog Timer (WDT):
- Programmable period from 4 ms to 131s
Single-Supply In-Circuit Serial Programming™
(ICSP™) via Two Pins
In-Circuit Debug (ICD) with Three Breakpoints via
Two Pins
Power-Managed modes with Clock Switching:
- Run: CPU on, peripherals on
- Idle: CPU off, peripherals on
- Sleep: CPU off, peripherals off
Peripheral Highlights:
• High-Current Sink/Source 25 mA/25 mA
(PORTB and PORTC)
• Three Programmable External Interrupts
• Four Input Change Interrupts
• One Capture/Compare/PWM (CCP) module
• One Enhanced Capture/Compare/PWM (ECCP)
module:
- One, two or four PWM outputs
- Selectable polarity
- Programmable dead time
- Auto-shutdown and auto-restart
• Two Master Synchronous Serial Port (MSSP)
modules supporting 3-Wire SPI (all 4 modes) and
I
2
C™ Master and Slave modes
• One Enhanced Addressable USART module:
- Supports RS-485, RS-232 and LIN/J2602
- Auto-wake-up on Start bit
- Auto-Baud Detect (ABD)
• 10-Bit, up to 13-Channel Analog-to-Digital
Converter module (A/D):
- Auto-acquisition capability
- Conversion available during Sleep
- Self-calibration feature
• Dual Analog Comparators with Input Multiplexing
•
•
•
•
•
•
Flexible Oscillator Structure:
•
•
•
•
•
•
Two Crystal modes, up to 40 MHz
Two External Clock modes, up to 40 MHz
Internal 31 kHz Oscillator
Secondary Oscillator using Timer1 @ 32 kHz
Two-Speed Oscillator Start-up
Fail-Safe Clock Monitor:
- Allows for safe shutdown if peripheral clock
stops
Program Memory
Device
SRAM Data
Flash # Single-Word Memory
(bytes)
(bytes) Instructions
16K
32K
16K
32K
8192
16384
8192
16384
1024
1024
1024
1024
I/O
EUSART
MSSP
10-Bit
A/D (ch)
CCP/
ECCP
(PWM)
2/0
2/0
1/1
1/1
1
1
2
2
SPI
Y
Y
Y
Y
Master
I
2
C™
Y
Y
Y
Y
Comparators
2
2
2
2
PIC18F24J10
PIC18F25J10
PIC18F44J10
PIC18F45J10
21
21
32
32
10
10
13
13
1
1
1
1
©
2009 Microchip Technology Inc.
DS39682E-page 1
Timers
8/16-Bit
1/2
1/2
1/2
1/2
