IMC-0805-01
Vishay Dale
Wirewound, Surface Mount Inductors
FEATURES
•
•
•
•
High self-resonant frequency values
High Q values at higher frequencies
Wirewound construction
Compatible with vapor phase and infrared reflow
soldering
• Tape and reel packaging for automatic handling,
2000/reel
• Compliant to RoHS Directive 2002/95/EC
• Halogen-free according to IEC 61249-2-21 definition
STANDARD ELECTRICAL SPECIFICATIONS
IND.
(nH)
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10 000
TEST
FREQ.
(MHz)
L
Q
250 1000
250 1000
250 1000
250 1000
250 1000
250 1000
250 1000
250 1000
250 500
250 500
250 500
250 500
250 500
250 500
250 500
250 500
200 500
200 500
200 500
150 500
150 500
150 250
100 250
100 250
100 250
100 250
100 250
100 250
25.2 100
25.2 100
25.2 100
25.2 100
25.2 50
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
2.52 2.52
Q
MIN.
50
35
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
50
50
50
50
45
45
45
45
45
35
35
35
15
15
15
15
15
15
15
15
15
15
15
10
SRF
MIN.
(MHz)
6000
6000
6000
6000
5800
5800
5500
5500
4800
4100
3600
3400
3300
2600
2400
2100
1700
1600
1450
1350
1200
1100
950
900
860
850
800
780
375
340
188
215
200
200
200
120
110
100
70
60
50
45
45
40
40
DCR RATED DC
MAX. CURRENT
()
(mA)
0.06
800
0.08
800
0.08
800
0.06
600
0.06
600
0.08
600
0.06
600
0.06
600
0.08
600
0.08
600
0.08
600
0.08
600
0.10
600
0.12
600
0.15
500
0.18
500
0.15
500
0.25
500
0.27
500
0.32
500
0.43
500
0.48
500
0.56
400
0.78
400
1.00
400
1.46
350
1.65
300
2.20
210
0.95
500
1.10
450
1.20
400
1.50
300
2.13
180
2.60
150
2.90
130
3.00
120
3.10
110
3.50
100
2.30
210
2.50
200
2.80
180
3.00
160
3.20
130
3.50
120
5.00
80
TOL.
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
ELECTRICAL SPECIFICATIONS
Inductance Range:
2.2 nH to 10 000 nH
Inductance and Tolerance:
0.3 nH for 2.2 nH to 4.7 nH,
± 5 % for 5.6 nH to 10 000 nH
Operating Temperature:
- 40 °C to + 125 °C
Core Material:
Ceramic from 2.2 nH to 390 nH; Ferrite from
470 nH to 10 000 nH
TEST EQUIPMENT
• Inductance and Q measured on HP4286A (2.2 nH to
390 nH) and HP4285A (470 nH to 10 000 nH)
• SRF is measured on HP8753E
• DCR ismeasured on HP4338B
DIMENSIONS
in inches [millimeters]
0.079 ± 0.008
[2.00 ± 0.2]
0.050 ± 0.008
[1.25 ± 0.2]
0.016 ± 0.008
[0.40 ± 0.2]
0.02 [0.5]
0.048 ± 0.008
[1.20 ± 0.2]
DESCRIPTION
IMC-0805-01
10 nH
±5%
ER
e4
(1)
MODEL
INDUCTANCE VALUE
INDUCTANCE TOLERANCE
PACKAGE CODE
JEDEC LEAD (Pb)-FREE STANDARD
Note
(1)
For parts within 2.2 nH to 390 nH please use e4 for JEDEC lead (Pb)-free standard. For parts within 470 nH to 10 000 nH please use e3 for
JEDEC lead (Pb)-free standard.
GLOBAL PART NUMBER
I
M
C
0
8
SIZE
0
5
E
R
1
0
INDUCTANCE
VALUE
N
J
TOL.
0
1
PRODUCT FAMILY
PACKAGE
CODE
SERIES
Document Number: 34115
Revision: 24-Feb-11
For technical questions, contact:
magnetics@vishay.com
www.vishay.com
1
