Features
■
Shielded construction
■
Inductance range: 1 to 1000 µH
■
Heating current up to 9.4 A
Applications
■
Automotive systems:
■
AEC-Q200 qualified
■
RoHS compliant* and halogen free**
- Driver assistant
- Information
- Entertainment
- Lighting
■
DC/DC converters
■
Power supplies
47
0
SRR1260A Series - Shielded Power Inductors
Electrical Specifications @ 25 °C
Bourns
Part Number
Q
Tol.
Test Frequency/
(Ref.)
(%)
Voltage
Inductance
Test
Freq.
(MHz)
SRF
(MHz)
Typ.
DCR
(mΩ)
Max.
I rms
(A)
I sat
(A)
General Specifications
Operating Temperature
................................-40 °C to +125 °C
(Temperature rise included)
Storage Temperature
................................-40 °C to +125 °C
Resistance to Soldering Heat
............................. +245 °C for 10 sec.
Temperature Rise
......................40 °C typ. at rated I rms
Inductance Drop .......... 25 % typ. at I sat
Materials
Core ..............................................Ferrite
Wire ............................Enameled copper
Terminal Finish ...................................Sn
Packaging .................... 600 pcs. per reel
Product Dimensions
12.5
±
0.3
(.492
±
.012)
L
(µH)
SRR1260A-1R0Y
SRR1260A-1R2Y
SRR1260A-1R5Y
SRR1260A-2R2Y
SRR1260A-2R4Y
SRR1260A-3R3Y
SRR1260A-3R5Y
SRR1260A-4R7Y
SRR1260A-5R6Y
SRR1260A-6R1Y
SRR1260A-6R8Y
SRR1260A-7R6Y
SRR1260A-8R2Y
SRR1260A-100M
SRR1260A-120M
SRR1260A-150M
SRR1260A-180M
SRR1260A-220M
SRR1260A-270M
SRR1260A-330M
SRR1260A-390M
SRR1260A-470M
SRR1260A-560M
SRR1260A-680M
SRR1260A-820M
SRR1260A-101M
SRR1260A-121K
SRR1260A-151K
SRR1260A-181K
SRR1260A-221K
SRR1260A-271K
SRR1260A-331K
SRR1260A-391K
SRR1260A-471K
SRR1260A-561K
SRR1260A-681K
SRR1260A-821K
SRR1260A-102K
1.0
1.2
1.5
2.2
2.4
3.3
3.5
4.7
5.6
6.1
6.8
7.6
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±30
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
100 KHz/0.1 V
100 KHz/0.1 V
100 KHz/0.1 V
100 KHz/0.1 V
100 KHz/0.1 V
100 KHz/0.1 V
100 KHz/0.1 V
100 KHz/0.1 V
100 KHz/0.1 V
100 KHz/0.1 V
100 KHz/0.1 V
100 KHz/0.1 V
100 KHz/0.1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
1 KHz/1 V
26
18
24
22
18
20
22
19
19
21
20
16
18
32
27
25
28
29
26
27
22
22
24
22
25
26
26
20
26
22
20
22
20
18
22
18
20
30
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.252
100
91.1
86
70
63.8
40
37.6
36.7
33
29.8
28.2
27.9
24
21
19.4
17.6
15.5
13.4
12.7
9.97
10.4
7.63
7.92
7.43
6.85
6.07
5.5
5
4.5
4.2
3.6
3.2
2.8
2.6
2.4
2.2
2
1.8
7.8
8.0
9.5
10.5
11.5
12.0
13.0
15.5
16.2
17.0
18.0
19.0
19.5
20.0
23.0
27.0
36.0
43.0
45.0
60.0
70.0
86.0
100
110
145
180
210
260
320
380
450
580
700
820
1000
1150
1500
1700
9.4
9.2
8.8
8.2
7.8
7.6
7.5
6.8
6.7
6.6
6.3
6.0
5.7
5.5
5.2
5.0
4.2
4.0
3.6
3.0
2.8
2.6
2.3
2.1
1.95
1.7
1.65
1.55
1.4
1.38
1.3
1.15
1.08
0.95
0.88
0.8
0.73
0.68
10.0
9.8
9.0
8.5
8.0
7.8
7.6
7.0
6.9
6.8
6.5
6.2
5.8
5.5
5.0
4.6
3.9
3.7
3.3
2.8
2.7
2.5
2.2
2.1
1.9
1.7
1.65
1.55
1.4
1.3
1.2
1.1
1.0
0.9
0.8
0.75
0.63
0.6
100
12.5
±
0.3
(.492
±
.012)
6.0
±
0.5
(.236
±
.020)
5.0
±
0.3
(.197
±
.012)
7.0
TYP.
(.276)
Recommended Layout
5.4
(.213)
2.9
(.114)
How to Order
Electrical Schematic
SRR1260A - 100M
Model
Value Code (see table)
* RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
** Bourns follows the prevailing definition of “halogen free” in the industry. Bourns considers a product to be
“halogen free” if (a) the Bromine (Br) content is 900 ppm or less; (b) the Chlorine (Cl) content is 900 ppm or less;
and (c) the total Bromine (Br) and Chlorine (Cl) content is 1500 ppm or less.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device
performance may vary over time.
Users should verify actual device performance in their specific applications.
6.8
(.268)
2.9
(.114)
DIMENSIONS:
MM
(INCHES)
SRR1260A Series
Line Filter
SRF0504 Series
- Shielded Power Inductors
Soldering Profile
Peak Temperature 245
max.
Max. Peak Temperature -5
30 sec. max.
Max. Time Above 217 : 60~150 sec. max.
Temperature
Rising Area
+4.0 °C/Sec. Max.
Inductance vs. DC Current Plot
10 3
7
5
Forced
Cooling Area
-(1.0~5.0) °C/Sec. Max.
Preheat
Area
150~200 °C / 60~120 Sec.
Reflow
Area
+3.0 °C/Sec. Max.
3
2
10 2
7
5
Inductance (µH)
250
Peak Temperature: 245 °C
217 °C
Temperature (°C)
-101M
-470M
200
150
100
50
60~120 Sec.
60~150 Sec.
60 Sec.
Max.
3
2
10 1
7
5
-220M
-100M
0
50
100
150
200
250
Time (Seconds)
3
2
10 0
10 1
2
3
5
7
1 02
2
3
5
7 10 3
2
3
5
7
10 4
DC Current (mA)
Packaging Specifications
330
DIA.
(12.99)
2.0
±
0.5
(.079
±
.020)
30.4
(1.197)
13.0
(.512)
DIA.
60.0 -0
(2.362 -0)
13.0
DIA.
(.512)
26 +0
(1.024 +0)
21.0
±
0.8
(.827
±
.031)
24.0
(.945)
4.0
(.157)
END
16.0
(.630)
START
NO COMPONENT
COMPONENTS
NO COMPONENT
400
(15.75)
400
(15.75)
DIMENSIONS:
MM
(INCHES)
USER DIRECTION OF FEED
QTY: 600 PCS. PER REEL
REV. 11/14
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
